Gold Note Vasari Gold Owner's Manual

VASARI GOLD
OWNERʼS MANUAL
Thank you for your purchase of the Vasari Gold stereo cartridge.
Read these Operating Instructions carefully before using your Vasari Gold and keep it for future reference.
1. The Stylus is very delicate. Applying excessive force to the stylus, such as pressing with a finger can break it. Handle the
cartridge with the utmost care.
2. A powerful magnet is used in the cartridge. Note that carelessly bringing a steel screwdriver or other such item near the
cartridge will result in it being attracted by the magnet and may result in damage to the stylus, so care must be taken.
Package Content
• Cartridge body
• Stainless Steel no-magnetic two sets of head-shell fixing 2,5mm screws
• Ownerʼs Manual
Method of Use
1. Mounting the cartridge on the tone arm Head-Shell
using the supplied Allen Wrench and one set of the 2,5mm
screws. Adjust it to the stylus position specified for the
turntable system you are using mounting it properly
without tilting or turning it. (See Figure 1.)
• The output terminals are colours coded for identification
as illustrated in Figure 2.
Match the colors of the tone arm head-shell leads to the
terminals and connect each other properly.
NOTE:
When connecting the cartridge, be sure to use the tipped
leads and press them onto the terminals.
Applying heat to the output terminals of the cartridge, such
as in direct soldering, will cause internal damage to the
cartridge, such as wire breakage.
GOLD NOTE
il suono italiano
Before Using
x2
BLUE
(Left ch. -)
WHITE (Left ch. +)
RED (right ch. +)
