PoE Power Rack Installation Guide

AC Distribution Panel

There are three EN60320 C20 AC input sockets on the rear panel of the device rated at 20A @ 250VAC. Each
socket supplies one power supply module. There is an AC power ON/OFF switch beside each AC input socket.

DC Distribution Panel

The DC distribution panel has two 10 mm
Switch 7750 chassis.
Figure 2-4 Distribution panel
Pin
7
8
9
2
Copper bus bars and two cables to connect the power rack the
2-4
Chapter 2 System Description
Definition
Not used
Not used
Not used
