Swann DVR4-NET-PLUS SW243-4NU Specifications page 2

DVR4-Net-PLUS™
4 Channel Digital Video Recorder
for Network & Web Monitoring with USB
The Swann DVR4-Net-Plus is the next generation of DIY security safety monitoring. Featuring
four standard composite video inputs and 2 video outputs. It is the ideal CCTV system for
small retail stores, homes or as a replacement for old fashioned time lapse recorders.
Integrated motion activated recording also makes it ideal for covert observation systems.
Control of the unit is via the front panel controls and on-screen display menu. Video
recording is activated manually via alarm-inputs or automatically via built-in motion detection.
Model
Motion Trigger Recording
Record Mode
Audio Input
Audio Output
Alarm Input
Alarm Output
Video Format
Hard Disk Storage
Compression Format
Camera Input Signal
Primary Monitor Output
Secondary Monitor Output
Additional Monitor Output
Display Resolution
Record Resolution
Display Frame Rate
Record Frame Rate
Picture In Picture
Key Lock
Video Adjustable
Simplex/Duplex/Triplex Operation
Time Display Format
Network Interface
PTZ control
Communication Port
Remote Controller
Backup
USB
Operating Temperature
Dimensions H x W x D
Power Supply
Picture used on packaging are for illustration purposes only.
MONITORING
Full Function
Yes
Manual / Sensor / Timer / Motion Detection
4 audio inputs (RCA)
1 audio inputs (RCA)
NO or NC, 4CH
NO or NC, 1CH
PAL/CCIR (AUS, NZ, UK) OR NTSC/EIA (USA)
Supported up to 400GB HDD
Modified Mjpeg
Composite video signal 1 Vp-p 75Ω BNC, 4 Channels
Composite video signal 1 Vp-p 75Ω BNC
Composite video signal 1 Vp-p 75Ω BNC
Super Video: S-Video, PS/2 x 1
720 * 576 (PAL), or 720 * 480 (NTSC)
720 * 288 or 360 * 288 (PAL), 720 * 240 or 360 * 240 (NTSC)
400 FPS (PAL), 480FPS (NTSC)
50 FPS or 100 FPS (PAL), 60 FPS or 120 FPS (NTSC)
Yes (Multi PIP)
Yes
Hue/ Color/ Contrast / Brightness Adjustable
Triplex
YY/MM/DD, DD/MM/YY, MM/DD/YY, OFF
RJ45 (LAN, INTERNET)
YES
RS485
Yes
USB, CDRW
USB 1.1
41ºF ~ 122 ºF / 5ºC ~ 50 ºC
3" x 17" x 13" / 67 x 430 x 320mm
12V
FRONT
Monitor living area
Monitor your children
in the backyard
Monitor front door
Package Contents:
• 6 x BNC to RCA Adapters
• DVR4-Net-PLUS
• Remote Control
• Hard Drive Tray & Key
• Power Adapter
• Instructional Manual
• Power Cable
• Remote Viewing Software
(PC Only)
BACK
We recommend
using high quality USB
Thumb Drives Only *
Home Parking Lot
Business Backyard
Monitor nursery
Use your
Monitor or TV
DVR4Net-PLUS
Requires 2 AA batteries (not included)
(Manual only available in English)
