SBS -600 Graphical Digital Multimeter
SBS- 700 Multi-Function Oscilloscope
Quick Start Guide
Quick start guide will explain basic information about the unit.
For complete Operation and Safety Information, Please refer to the
SBS-600/700 Quick Start Guide
99 Washington Street
Melrose, MA 02176
Phone 781-665-1400
Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com
Revision 1.0 -5/2014
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SBS SBS-600
Summary of Contents for SBS SBS-600
- Page 1 SBS -600 Graphical Digital Multimeter SBS- 700 Multi-Function Oscilloscope Quick Start Guide 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com Quick start guide will explain basic information about the unit. For complete Operation and Safety Information, Please refer to the SBS-600/700 Quick Start Guide Revision 1.0 -5/2014...
- Page 2 : Power Supply OFF : Power Supply ON : Warning of Electric Shock : Warning of Danger : CategoryⅡ 1000V Overload Protection(Multi-meter Function :Model SBS-600 SBS-700 ) : CategoryⅢ 600V Overload Protection(Multi-meter Function Model SBS-600, SBS-700) : CategoryⅢ 300V Overload Protection(Scope Function, Model . SBS-700)
- Page 3 [WARNING Pay attention when testing conditions exceed 60V DC, 30V AC rms or 42.4V AC Peak that can cause an electric shock. Do not connect the Ground wire to voltage higher than 0V DC, 30V AC rms or 42.4V AC Peak. ...
- Page 4 WEEE (Waste Electrical and Electronic Equipment) (2002/96/EC) Meter complies with WEEE (2002/96/EC) requirements. Do not dispose Electric / Electronics device with other trash. Front View Key Pad The Keys are different by models. [Main Functional Keys]...
- Page 5 SBS - 600 SBS - 700 Function and Menu selections automatically take effect 2 seconds after pressing the key. If the user Prefers immediate setting Pressing the ENTER key will immediately select the Function or Menu. Voltage measurement keys : AC+DC, DC, AC...
- Page 6 [Secondary Function Key] [ Secondary Function Keys ] Function key Function Description Selects Sub Menu functions and modes after (main) Menu selection. Upper Line: (Short Key) One Touch press Enter Menu (Main Menu) functions and modes. Lower Line: (Long key) Press longer than 2 seconds to enter USER.
-
Page 7: Lcd Display
I (Help): (Short Key) One Touch press to enter Help mode. Brief Information on present function is displayed. Back Light On/Off: Hold longer than 2 seconds to enter Back Light display mode. Help: short key(50ms), Backlight: long key(2s) Turn the meter power ON / OFF Hold Longer than 2 seconds to power ON / OFF Cursor buttons select an item in Menu. - Page 8 DMM Screen Description symbol Minimum. Maximum, Average measurement Can select Measuring Range in Automatic method or Manual method Freeze the present reading in display. Freeze the present reading in display. Sub Menu The Subsidiary Menu. After main menu selected, sub menu tree show up to select Bar-Graph Input Signal is displayed in Bar-Graph.
-
Page 9: Data Logger Screen
Data Logger Screen Symbol Description Measuring Mode. (DCV, ACV, Ohm, Capacitance, Diode) RUN and STOP of Data Logger function Run Time Accumulated Sample Q‘ty in Data Logger. Maximum Display Range Minimum, Maximum , Average of the Samples Total Time Scale of Data Logging. Present Measurement Value Change the Time Scale (left - right horizontal axis) to review closely on the specific Time Zone. - Page 10 Logic Analyzer Screen Protocol Analyzer Screen [Logic Analyzer, Protocol Analyzer Display Symbol] Symbol Description Logic Analyzer: Pattern, Duration Condition Protocol Analyzer: CAN, LIN, I2C, UART, USB, I2S SMBus, SPI, DMX512, 1-Wire Time/div Measurement Time/div Indicator Channels Displays all the Input Channels Horizontal Time Division &...
-
Page 11: Pattern Generator
Pattern Generator [Pattern Generator Display Symbol] Symbol Description Condition UART, CAN, User Defined Time/div Measurement Time/div Indicator Channels Displays all the Channels (TX/RX) Selection of Transaction/Message, Acquisition Mode, View and Cursor adjustment Selection of Trigger condition, Trigger Level, Condition and Baud rate used to decide the speed of pattern Message Used for making the format, cycle, and data of each pattern Output... -
Page 12: Input Terminals
Input Terminals To prevent from Damage, Do not apply exceeding the Rate. SBS - 600 ** CAT III 300 V for Scope input SBS - 700 Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com... - Page 13 AUX (auxiliary function with external adapter : Temperature, High Current, Relative Humidity, Pressure Sig-out( ) measurement) 13 pin socket 13 pin socket Terminal (Measurement and Output) : Logic Analyzer, Terminal ( SBS-700) Pattern Generator, Protocol Analyzer, Sig- Out Rear View and Side View...
- Page 14 User should pay attention at the Voltage Rating and Over Voltage warning. Immediately remove the Test Lead/Test Probe from the METER when VOLTAGE WARNING comes on. Scope function Input (model SBS-700), max 300V. Other Multi-meter function Input (models SBS-600, SBS-700 ), max 600V.
- Page 15 “OL”. Power 6*AA Alkaline Battery ( SBS-600 only ) 7.2V NiMH Battery Pack or AC Power Adapter ( SBS-700 only ) Remaining Battery Capacity Level indicator Top right display indicates Remaining Battery Capacity Level,...
-
Page 16: General Maintenance
Back Light Display When measurement environment is dark or it is hard to see the LCD display, hold Back Light key longer than 2 seconds, Back Light operation time can be set in USER mode Measurement Range selection (Auto/Range) ... - Page 17 Model SBS-700 uses only the supplied 7.2V NiMH Rechargeable Battery Pack. When Battery low signal is blinking, In the model SBS-600, replace with New AA Alkaline battery cell as soon as possible. In the model SBS-700, recharge the battery pack as soon as possible.
