- Page 1 Digital Hydrometer SBS-2500 INSTRUCTION MANUAL Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 TestEquipmentDepot.com Storage Battery Systems LLC • Instruction Manual for SBS-2500 Digital Hydrometer • Rev. 09-15...
-
Page 2: Table Of Contents
Table of Contents Introduction ................................4 Safety Measures ............................... 4 Description of the Instrument ..........................5 SBS-2500 .................................. 5 Display ..................................5 Keys ..................................5 Tutorial ..................................7 Inserting batteries ..............................7 Configuration ................................7 Test measurement ..............................8 Adjustment ................................8 Cleaning .................................. -
Page 3: Introduction
1. Introduction to the SBS-2500 The SBS-2500 is a portable measuring instrument suited for determining the density of liquids. The instrument uses the oscillating body method. To fill the measuring cell the built-in sample pump or a syringe may be used. The results are automatically calculated into one of the following units: density, specific gravity, API degrees, Brix, % Alcohol, % H2SO4, Baumé, Plato, Proof or a user-defined unit. -
Page 4: Description Of The Instrument
Fixing screw for sample tube Sample tube Measuring cell 10. Infrared interface 11. Lock button 12. Fill button 13. Battery compartment cover Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 TestEquipmentDepot.com Page 4 SBS-2500 Manual 09-15-TI2500... -
Page 5: Display
Appears if “Memory” out is set to “Auto”. If a printer or PC is connected, the data are transferred automatically Battery-power indicator Temperature (°C / °F) 10. Appears if delete mode is activated 11. Mark for results For the identification of invalid or incorrect results or for marking a sample change ∆ Reference temperature (for the units “Comp. Density” and “SG” only) Page 5 SBS-2500 Manual 09-15-TI2500... -
Page 6: Keys
Exit the menu Switch instrument on or off ok/meas. • Start measurement • Confirm input • Confirm data delete • Confirm data transfer • While pressing and holding key 5: enter the menu Note Only the arrow symbols are used to represent keys 1 – 4 in the following operation instructions. Page 6 SBS-2500 Manual 09-15-TI2500... -
Page 7: Tutorial
4. Tutorial 4.1 Inserting Batteries Open the battery compartment cover on the back of the SBS-2500. Remove battery compartment. Insert batteries into the battery compartment, observing correct polarity. Insert battery compartment, ensuring that the contacts of the battery compartment face the instrument. -
Page 8: Test Measurement
Press and hold the “esc” key until the display is turned off. The instrument is now turned off. Switching on Press and hold the “esc” key until the display appears. The instrument is ready for operation. Page 8 SBS-2500 Manual 09-15-TI2500... -
Page 9: Menu
5. Menu The menu of the SBS-2500 offers the following functions: Measurement Unit (Measure Unit) see Chapter 5.2 Temperature Unit (Temp. Unit) see Chapter 5.3 Measure Mode see Chapter 5.4 Adjust Mode (Calib. Mode) see Chapter 5.5 Interface see Chapter 5.6 Beep see Chapter 5.7... -
Page 10: Measurement Unit (Measure Unit)
H2SO4 (Sulfuric acid concentration) Measurement of the sulfuric acid concentration, percent weight at 20°C. Baume (°Baumé scale) Measurement in °Baumé (heavy Baumé for d > 1, light Baumé for d < 1) calculated to a reference temperature. 10 temperature-compensation coefficients can be saved. Input of temperature-compensation coefficients via Comp. Density. For typical temperature-compensation coefficients, see Chapter 13.2; calculation of α, see page 1. Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 Page 10 TestEquipmentDepot.com SBS-2500 Manual 09-15-TI2500... - Page 11 0.7937 - 1 / 26 - 15 0.7844 α = (1.011856 - 1) / 11 = 0.011856 / 11 = 0.001078 α x 1000 = 1.078; enter this value into the instrument. 10 temperature-compensation coefficients can be saved. Input of temperature-compensation coefficients via Comp. Density. For typical temperature-compensation coefficients, see Chapter 13.2. Page 11 SBS-2500 Manual 09-15-TI2500...
-
Page 12: Temperature Unit (Temp. Unit)
Serial interface. The Excel macro “PortableCapt” for data transfer to the computer via the infrared adapter is located on the CD. IrDA Data transfer to the PC with the integrated IrDA interface in accordance with protocol 1.20 5.7 Beep Beep off. Beep on. Page 12 SBS-2500 Manual 09-15-TI2500... -
Page 13: Background Lighting And Lcd-Contrast (Lcd)
• Are homogeneous (no emulsions or suspended particles, no air bubbles); • Have reached ambient temperature in the measuring cell. For samples which are 20°C colder than the ambient temperature, heat the sample before beginning the sampling procedure. Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 Page 13 TestEquipmentDepot.com SBS-2500 Manual 09-15-TI2500... -
Page 14: Filling The Measuring Cell Using The Built-In Sample Pump
Hold the sample tube over a waste container. • Slowly inject the sample into the measuring cell. • Ensure that there are no air bubbles in the measuring cell. • Do not remove the syringe while measuring. Page 14 SBS-2500 Manual 09-15-TI2500... -
Page 15: Measuring
For the identification of invalid or incorrect results or for marking a sample change. • Select the desired sample number using the and keys. • Press the “ok/meas.” key. The selected sample number is marked with an asterisk. Page 15 SBS-2500 Manual 09-15-TI2500... -
Page 16: Printing And Transferring Results
Deleting Transferred Results • Press the or key. Execute? (Yes) appears. • Press the “ok/meas.” key to confirm. All results are deleted. Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 Page 16 TestEquipmentDepot.com SBS-2500 Manual 09-15-TI2500... -
Page 17: Deleting Results
6.8 Deleting Results It is not possible to delete individual results with the SBS-2500. Deleting all results Memory All Clear Execute? (No) appears in the display. • Press and hold the key until • Press the or key. -
Page 18: Adjusting The Measuring Cell With A Density Standard
Clean the cell if necessary and readjust. 7.3 Adjusting the Measuring Cell with Air The SBS-2500 measures with the specified accuracy if the measuring cell is correctly adjusted with the accompanying density standard or distilled water. Additional adjustment with air is generally not necessary, but is recommended when: •... -
Page 19: Adjusting The Temperature Display
Adjust measuring cell with water or a density standard of your choice. 7.4 Adjusting the Temperature Display Adjustment of the temperature display is generally not necessary, as the SBS-2500 was adjusted at the factory before shipment. If the displayed temperature deviates from the actual temperature, carry out the following steps for adjustment: •... -
Page 20: Interface
–0.4 (°C) 8. Interface Using the infrared interface of the SBS-2500, the stored measurements together with the sample identification, the measurement unit, the temperature, the temperature compensation coefficient, the instrument identification, date and time can be printed out with a printer or transferred to a PC. -
Page 21: Data Format
If RS is selected as interface, the data is transferred in the following format: Sample identification (a…z, space) If result is marked (*); otherwise, space Format yyyy/mm/dd hh:mm Temperature unit (°C or °F) Number of the temperature-compensation coefficient These bytes contain only spaces, unless Comp. Density, SG, °Baumé or Conc. is selected as the result unit Page 21 SBS-2500 Manual 09-15-TI2500... -
Page 22: Error Messages And Malfunctions
Call SBS Test Equipment Service E-07 Measuring time of 10 minutes exceeded • Switch instrument off and on again • Measure using bubble-free, distilled water If error appears again: Call SBS Test Equipment Service BATT Batteries empty Replace batteries (see Chapter 4.1) Set Calib. Mode to off Result = 0.0000 or strongly negative results: Menu setting incorrect Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 Page 22 TestEquipmentDepot.com... -
Page 23: Cleaning And Maintenance
Repeat cleaning if necessary. 10.2 Cleaning the Housing • Never use aggressive liquids or solvents to clean the housing of the SBS-2500. • We recommend that you use the cleaning tissues which come with the instrument. 10.3 Replacing the Sample Tube •... -
Page 24: Standard Equipment
11. Standard Equipment The instrument is delivered pre-assembled with the following equipment. SBS-2500 AAA Batteries (LR03, 1.5V) CD-ROM Operating instructions IR Adapter Page 24 SBS-2500 Manual 09-15-TI2500... -
Page 25: Technical Data
1 - 10 minutes Data memory 1100 results Interface Infrared for printer and PC Battery operation 2 x 1.5 V batteries (LR03); type AAA Battery lifetime Approximately 90 hours (with backlighting off) Subject to technical changes. Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 Page 25 TestEquipmentDepot.com SBS-2500 Manual 09-15-TI2500... -
Page 26: Appendices
.99910 .99894 .99878 .99860 .99841 .99821 .99799 .99777 .99754 .99730 .99705 .99679 .99652 .99624 .99595 .99565 .99534 .99503 .99471 .99438 .99404 .99369 .99333 .99297 .99260 .99222 [Chemical Handbook Fundamental Version, Rev. 3, Table 5.2 (1984)] Page 26 SBS-2500 Manual 09-15-TI2500... - Page 27 Bromobenzene 0 - 30 0.91 Cyclohexane 0 - 30 1.20 Isopropanol 0 - 30 1.06 n-nonane 0 - 30 1.08 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com Page 27 SBS-2500 Manual 09-15-TI2500...
