- Page 1 SSA3000X Series Spectrum Analyzer Quick Guide...
-
Page 2: Copyright Information
Copyright Information SIGLENT TECHNOLOGIES CO., LTD. All Rights Reserved. Information in this publication replaces all previously corresponding material. SIGLENT reserves the right to modify or change parts of or all the specifications or pricing policies at company’s sole decision. Any way of copying, extracting or translating the contents of this manual is not allowed without the permission of SIGLENT. -
Page 3: General Safety Summary
Do Not Operate in an Explosive Atmosphere In order to avoid damage to the device or personal injury, it is important to operate the device away from an explosive atmosphere. SSA3000X Series Spectrum Analyzer... - Page 4 WARNING Indicates potential injuries or hazards that may happen. CAUTION Indicates potential damages to the instrument or other property that may happen. Symbols on the product. These symbols may appear on the product: Chassis Hazardous Protective Earth Warning Voltage Earth Ground Ground Ground SSA3000X Series Spectrum Analyzer...
-
Page 5: General Care And Cleaning
To avoid damages to the surface of the instrument, please do not use any corrosive liquid or chemical cleanser. Make sure that the instrument is completely dry before restarting it to avoid short circuits or personal injuries. SSA3000X Series Spectrum Analyzer... -
Page 6: General Inspection
If the instrument is found to be damaged, defective or fails in electrical or mechanical tests, please contact SIGLENT. 3. Check the accessories Please check the accessories according to the packing list. If the accessories are incomplete or damaged, please contact your SIGLENT sales representative. SSA3000X Series Spectrum Analyzer... -
Page 7: Appearance And Dimension
Appearance Dimension Figure 1 Front View Figure 2 Top View SSA3000X Series Spectrum Analyzer... -
Page 8: Adjust The Supporting Legs
Adjust the Supporting Legs Adjust the supporting legs properly to use them as stands to tilt the Spectrum Analyzer upwards for stable placement as well as easier operation and observation of the instrument. Before adjusting After adjusting SSA3000X Series Spectrum Analyzer... -
Page 9: Connect To Ac Power Supply
Connect to AC Power Supply The Spectrum Analyzer accept 100-240V, 50/60/440Hz AC power supply. Please use the power cord provided as accessories to connect the instrument to the power source as shown in the figure below. SSA3000X Series Spectrum Analyzer... -
Page 10: General Description
Description SSA3000X series spectrum analyzer has a frequency range from 9 kHz up to 2.1 GHz/3.2 GHz. It is lightweight, small and precise, offering a user friendly interface, clear display with plenty of RF measurement functions. The product can be used for research and development, education, production, maintenance and other relevant applications. - Page 11 Marker: Used to Select the Mark Trace and Marker math Marker→: Sets all types of Markers to Freq Marker Fn: Selects the Noise Marker\N dB BW\Freq Counter\Read out of Freq Peak: Searches for the Peak Signal and Counts the Peak Frequency SSA3000X Series Spectrum Analyzer...
- Page 12 Display: Used to Adjust the Grid Brightness\Display Line File: Use to Select the File system Preset: Sets the system to default status Couple: Used to Select the RBW\VBW\Attenuator\Freq Step\Sweep time mode Help: Help Information Switch Save: Save Shortcut Key SSA3000X Series Spectrum Analyzer...
- Page 13 The Rear Panel 1、Handle 2、USB Device 3、LAN Interface 4、10MHz REF Input 5、10MHz REF Output 6、Trigger In 7、Safety Lock Hole 8、AC Power Socket SSA3000X Series Spectrum Analyzer...
- Page 14 To avoid damage to the instrument, make certain that the input signal to the RF input port does not contain more than 50 Volts DC. The AC (radio frequency) input signal component should not exceed a maximum continuous power level of +30dBm. 2. TG OUTPUT WARNING To avoid damage to the tracking generator, The reverse DC voltage must not exceed 50V SSA3000X Series Spectrum Analyzer...
- Page 15 User Graphical Interface 1、SIGLENT LOGO 6、Active parameter 2、4、5：Parameters setting area 7、Display area 3、Menu setting area SSA3000X Series Spectrum Analyzer...
-
Page 16: For More Product Information
SSA3000X Series User Manual: provides detailed introductions of the functions of this product; SSA3000X Series Programming Guide: provides detailed introductions of the SCPI commands and programming of this product; SSA3000X Series Datasheet: provides the main characteristics and specifications of this product;... - Page 17 Contact us SIGLENT TECHNOLOGIES CO., LTD. Address：3/F, building No.4, Antongda Industrial Zone, 3rd Liuxian Road, Bao’an District, Shenzhen, P.R.C. Tel:+86-755-36615186 E-mail:sales@siglent.com Http://www.siglent.com SSA3000X Series Spectrum Analyzer...
- Page 18 www.siglent.com...
