PSoC® CY8C24533, CY8C23533, CY8C23433 TRM
®
PSoC
CY8C24533, CY8C23533, CY8C23433
Technical Reference Manual (TRM)
Document # 001-20559 Rev. *D
January 19, 2017
Cypress Semiconductor
198 Champion Court
San Jose, CA 95134-1709
Phone (USA): 800.858.1810
Phone (Intnl.): 408.943.2600
http://www.cypress.com
