LATTIMORE SHOWER SET INSTALLATION
3. Remove the decorative screw cover from the valve
handle. Slide the handle onto the valve stem and
secure it by tightening the set screw with the provided
hex wrench. Reinsert the screw cover to conceal the
screw.
4. Install the hand shower cradle by threading it into its
prepared female fitting. Apply thread sealant or
plumber's tape to the threads before tightening. Hand
tighten firmly.
5. Attach the hand shower to the cradle using the
hand shower hose. Insert one of the provided rubber
O-rings into each end of the hose, and apply thread
sealant or plumber's tape to the threads before
tightening. Hand tighten the connections firmly.
6. Slide the decorative back plate onto the shower arm,
and install the shower arm by threading it into its
prepared female fitting. Apply thread sealant or plumb-
er's tape to the threads before tightening. Hand tighten
firmly.
