K E Y W E S T
PRESSURE BALANCE SHOWER VALVE AND TRIM
REGULADOR Y VÁLVULA DE DUCHA DE PRESIÓN BALANCEADA KEY WEST
SKU: 948307
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing plumbing �xtures. Signature
Hardware accepts no liability for any damage to the
plumbing, shower, wall, or for personal injury during
installation.
Observe all local plumbing and building codes.
Unpack and inspect the product for shipping
damage. If any damage is found, contact our
Customer Relations team at 1-800-221-3379.
ANTES DE COMENZAR
Le recomendamos que consulte a un profesional si no
sabe cómo instalar accesorios de plomería. Signature
Hardware no asume ninguna responsabilidad con
respecto a los daños causados a la plomería, la ducha,
la pared, ni por daños personales que ocurran durante
la instalación.
Cumpla con todas las normas locales de plomería y
construcción.
Retire el producto del empaque y verifique si se
produjeron daños durante el envío. Si encuentra algún
daño, comuníquese con nuestro equipo de Servicio al
cliente al 1-800-221-3379.
GETTING STARTED
Ensure that you have gathered all the required
materials that are needed for the installation.
CÓMO COMENZAR
Asegúrese de haber reunido todos los materiales
necesarios para la instalación.
TOOLS AND MATERIALS:
HERRAMIENTAS Y MATERIALES:
Adjustable Wrench
Llave Ajustable
Safety Glasses
Gafas de seguridad
Neutral Cure
Silicone Sealant
Sellador de silicona
de curado neutro
Thermometer
Termómetro
1
Flathead
Phillips
Screwdriver
Screwdriver
Destornillador de
Destornillador
cabeza plana
Phillips
Keyhole Saw
Tape Measure
Sierra de punta
Cinta métrica
Groove Joint Plier
Plumbers Tape
Pinzas ajustable
Cinta Selladora
Para Rosca
Strap Wrench
Llave de correa
REVISED 01/26/2021
CODES: SHKW8010, SH4001
1.800.221.3379
