Venue 2 Wideband Receiver
TALKBACK enables the Talkback Mode on
the desired channels and selects the
output channel for the talkback audio.
GROUP TUNING opens setup and editing
screens to select and modify user defined
frequency groups U, V, W and X, or NONE
for each receiver module.
SQUELCH BP bypasses the squelch
(muting) function on a per module basis for
diagnostic purposes.
CAUTION: Reduce the gain or volume
level of the sound system or recorder before
bypassing the squelch. Very loud noise will be
present at the bypassed channel.
MODULE POWER turns the power ON or
OFF on each receiver module. Normally
used to prolong operating time when the
receiver is powered by battery.
