Refer To This Picture For Next 2 Steps; Cylindrical Housing - Command access CYLP-UL-M-KIT Installation Instructions

Field-installable motorized latch-pullback kit for the corbin 4000/5000 and yale 7000 series exit devices
Hide thumbs
1
2
3
4
5
Table of Contents

Advertisement

Refer to this picture for next 2 steps

2
1
B. Using Hex wrench supplied tighten hex screw #1 to secure assembly to the device.
C. Using 1/16" Hex wrench supplied tighten hex screw #2 to lift assembly block until it's level.
Acme Thread
D. Slide motor mount into the device. While sliding into position, feed acme screw into cylindrical housing.

Cylindrical housing
