Summary of Contents for IKEA RENGORA
- Page 1 RENGÖRA...
- Page 2 ENGLISH Please refer to the last page of this manual for the full list of IKEA appointed After Sales Service Provider and relative national phone numbers.
- Page 3 ENGLISH...
-
Page 4: Table Of Contents
Programmes Technical information Settings Environmental concerns Before first use IKEA guarantee Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. -
Page 5: General Safety
ENGLISH Children shall not carry out cleaning and user maintenance of • the appliance without supervision. General Safety This appliance is intended to be used in household and • similar applications such as: farm houses; staff kitchen areas in shops, offices and other –... -
Page 6: Safety Instructions
ENGLISH Safety instructions • Do not pull the mains cable to disconnect Installation the appliance. Always pull the mains Warning! Only a qualified plug. person must install this • This appliance complies with the E.E.C. appliance. Directives. • This appliance is fitted with a 13 A mains •... -
Page 7: Product Description
ENGLISH • Dishwasher detergents are dangerous. • Use original spare parts only. Follow the safety instructions on the Disposal detergent packaging. • Do not drink and play with the water in Warning! Risk of injury or the appliance. suffocation. • Do not remove the dishes from the appliance until the programme is •... -
Page 8: Control Panel
ENGLISH Control panel On/off button Indicators Programme buttons Delay button Indicators Indicator Description End indicator. Rinse aid indicator. It is always off while the programme operates. Salt indicator. It is always off while the programme operates. Programmes Programme Degree of soil Programme pha- Consumption values Type of load... -
Page 9: Settings
ENGLISH Programme Degree of soil Programme pha- Consumption values Type of load Duration Energy Water (min) (kWh) • Prewash Normal soil 1.050 • Wash 50 °C Crockery and 50 °C • Rinses cutlery • Dry • Prewash 1) The pressure and the temperature of the water, the variations of the mains supply, the options and the quantity of dishes can change the values. - Page 10 ENGLISH your area. Your local water authority can Press and hold simultaneously advise you on the hardness of the water in until the appliance is in programme your area. It is important to set the right selection mode. level of the water softener to assure good The water softener washing results.
- Page 11 ENGLISH The indicators: start 2. Press flashing. The indicators: are off. 2. Press The indicator still flashes. The indicators are off. The indicator shows the current setting. The indicator still flashes. If on = rinse aid empty notification is on, if off = rinse aid empty notification is off.
-
Page 12: Before First Use
ENGLISH AutoOpen To avoid possible hazards inside the appliance (such as knives, AutoOpen improves the drying results with sharp objects or chemicals) for less energy consumption. children, pets or people with disabilities deactivate the function. How to deactivate AutoOpen The appliance must be in the programme selection mode. - Page 13 ENGLISH The salt container Caution! Use rough salt designed for dishwashers only. Fine salt increases the risk of corrosion. The salt is used to recharge the resin in the water softener and to assure good washing results in daily use. Turn the cap of the Filling the salt container salt container...
-
Page 14: Daily Use
ENGLISH To adjust the released quantity of rinse aid, turn the selector between position 1 (lowest quantity) and position 4 (highest quantity). Daily use 1. Open the water tap. 2. Press the on/off button to activate the appliance. Make sure that the appliance is in programme selection mode. - Page 15 ENGLISH • After 5 minutes if the programme has not started. Starting a programme 1. Keep the appliance door ajar. 2. Press the on/off button to activate the appliance. Make sure that the appliance is in programme selection mode. 3. Press the button related to the programme you want to start.
-
Page 16: Hints And Tips
ENGLISH deactivate the appliance within 5 minutes, Press and hold simultaneously all indicators go off to decrease the energy until the appliance is in programme consumption. selection mode. 1. To deactivate the appliance, press the Cancelling the programme on/off button or wait for the Auto Off function to automatically deactivate the Press and hold simultaneously appliance. -
Page 17: Care And Cleaning
ENGLISH Loading the baskets Before starting a programme Before you start the selected programme, Refer to the supplied leaflet with make sure that: examples of the load of the baskets. • The filters are clean and correctly installed. • Only use the appliance to wash items •... - Page 18 ENGLISH Cleaning the filters Put the flat filter (A) Reassemble the back in place. Make filters (B) and (C). Make sure that The filter system is sure that it is Put them back in the there are no made of three parts. correctly positioned filter (A).
-
Page 19: Troubleshooting
ENGLISH • If you regularly use short duration Cleaning the spray arms programmes, these can leave deposits of Do not remove the spray arms. If the holes grease and limescale inside the in the spray arms are clogged, remove appliance. To prevent this, we remaining parts of soil with a thin pointed recommend to run long duration object. - Page 20 ENGLISH Problem and alarm code Possible cause and solution • Make sure that the appliance door is closed. The programme does not start. • If the delay start is set, cancel the setting or wait for the end of the countdown. •...
- Page 21 ENGLISH Problem and alarm code Possible cause and solution • The appliance is not levelled. Loosen or tighten Small leak from the appliance door. the adjustable feet (if applicable). • The appliance door is not centred on the tub. Adjust the rear foot (if applicable). The appliance door is difficult to close.
- Page 22 ENGLISH Problem Possible cause and solution • Tableware has been left for too long inside a closed Poor drying results. appliance. • There is no rinse aid or the dosage of rinse aid is not enough. Set the rinse aid dispenser to a higher level. •...
-
Page 23: Technical Information
ENGLISH Problem Possible cause and solution • Refer to "Internal cleaning". Odours inside the appliance. • The level of salt is low, check the refill indicator. Limescale deposits on the ta- • The cap of the salt container is loose. bleware, on the tub and on •... -
Page 24: Environmental Concerns
LAGAN or TILLREDA - from the original • The exceptions are specified under the date of purchase of your appliance at IKEA headline “What is not covered under this or from the installation date with maximum guarantee?” Within the guarantee limit of three months from the purchase period. - Page 25 • Transportation damages. If a customer transports the product to his home or What is not covered under this another address, IKEA is not liable for guarantee? any damage that may occur during • Normal wear and tear.
- Page 26 • ask for clarifications on installation of the purchased. IKEA appliance in the dedicated IKEA kitchen furniture; • ask for clarification on functions of IKEA appliances. To ensure that we provide you with the best assistance, please read carefully the Assembly Instructions and/or the User Manual before contacting us.
- Page 27 UNITED ARAB EMIRATES : رﻗﻢ ﻣﺠﺎﻧﻲ Toll free: 8 004 532 : ﻣﻮﻗﻊ اﻹﻧﺘﺮﻧﺖ Web: www.IKEA.com QATAR : رﻗﻢ ﻣﺠﺎﻧﻲ Toll free: 8 004 532 : ﻣﻮﻗﻊ اﻹﻧﺘﺮﻧﺖ Web: www.IKEA.qa : اﻟﺒﺮﻳﺪ اﻹﻟﻜﺘﺮوﻧﻲ e-mail: Ikea_qatar@alfuttaim.com EGYPT : اﻟﺨﻂ اﻟﺴﺎﺧﻦ Hotline: 16576 : ﻣﻮﻗﻊ...
- Page 28 21552 © Inter IKEA Systems B.V. 2019 AA-2171002-1...
