- Page 1 Near Infrared Grain Tester AN-820 Operating Manual...
-
Page 3: Table Of Contents
. Bias Adjustment ................... 16 (1) Manual adjustment mode ............... 17 (2) Automatic adjustment mode ............19 7. Time settings ..................8. Communication ....................22 9. Replacment for lamp ................10. Cleaning ....................... <Appendix> Guidelines for using AN-820 with maximum accuracy... -
Page 4: Features
1. Features The Model AN-820 composition analyzer is a desk top grain tester (Transmittance type) that utilizes applied near-infrared rice analysis technology. It employs total-grain measurement formulas for measuring without crushing the sample grain to pieces, so it makes it possible to analyze grain quickly and easily. -
Page 5: Main Unit & Parts Names
2. Main unit & Parts names < Front side > Cover Measurement chamber Contrast adjustment control Display Key functions < Rear side > Cover Power switch Printer output port Fuse holder Serial output port(RS-232C) Power cable connection... - Page 6 [ Accessories ] Sample case Power cable Fuse Sampling cup Storage container Standard samples Operating manual Standard samples Storage container for standard samples (Brown rice / Milled rice)
-
Page 7: Specifications
Note : AN-820 should be used below 35 in environment condition. If the environment temperature is ℃ over 50 , the precision spectroscope would be damaged. And The AN-820 should be also stor- ℃ aged below 50 environment condition. Note : Pre-calibration with recommended conditions are as below. -
Page 8: Keypad Explanation
4. Keypad Explanation Scroll key Enter key Function key Return key Enter key Press this key when you begin measuring or you want to execute or confirm a selected item. Return key Press this key when you want to return to a previous screen or when you want to invalidate a selected item. -
Page 9: Preparation
5. Preparation 5-1. Power ON Operation Display Explanation 1. Plug the power cable into this unit and connect it to outlet. Power Connector Power switch Power cable Outlet Ground 2. Turn the power switch “ON”, which is located rear side. Initial screen will be displayed. -
Page 10: Calibration Selection
5-2. Calibration Selection With near-infrared composition analyzers similar to this unit, you prepare each pre- calibration and then analysis compositions. AN-820 has an eight channel capacities and pre-calibrations is done by our company. Before starting analysis, please select a proper calibration according to the grain you want to measure. -
Page 11: Measuring Procedure
6. Measuring Procedure 6-1. Measuring Operation Display Explanation 1. By using keys, select the “Measurement” setting. ［ Measurement ］ ［ Application ］ 1 Short Brown ［ Display ］ ［ Adjustment ］ Serial number ［ Time ］ AB0 1 234 ［ Communication ］... - Page 12 Note : During and /or measurement, there are times when the following messages will be displayed. In whichever case except Error 09, press key, and redo the measurement from the very beginning. This message appears when stepping motor which works for transporting sample grain case for measurement is wrong thus Error 01 : sample case may stop moving on the way for measurement.
-
Page 13: Average Display
Display the average. Note : AN-820 utilizes a transmittance measurement method, empty space in the sample cases will lead to measurement errors. It is important into the sample case firmly in such a way that there are no empty spaces. -
Page 14: Setup The Display Conditions
6-3-1. Setup the Dislay Conditions Operation Display Explanation 1. By using keys, select the “Display” setting. ［ Measurement ］ ［ Application ］ 1 Short Brown ［ Display ］ ［ Adjustment ］ Serial number ［ Time ］ AB0 1 234 ［ Communication ］... -
Page 15: Setup The Indication Range
6-3-2. Setup the Indication Range Operation Display Explanation ［Display］Application 1 Short Brown 1. By using keys, select Q. E. V O N the “Indication range” setting. Protein O N Protein CM O N ＠ Moisture 1 5 . 0 ％ Protein DM OFF Moisture O N Amilose O N Indication range Select the item. -
Page 16: Protein Cm Display
This consideration is “CM Protein” which is displayed as protein conversion by assuming the fixed moisture content (with AN-820, this is the same as the “@ Moisture %” is specified). When the fixed moisture content is assumed to be “ 0% ”, this is referred to as a “dry conversion”... -
Page 17: Manual Adjustment Mode
Manual adjustment mode With manual setting, prepare 3 or 5 samples and calculate the difference between average value of AN-820 and average value of standard samples for each composition. Because this alternative uses multiple samples to perform the bias adjustment, it is able to perform more accurate bias adjustment than automatic adjustment. - Page 18 Operation Display Explanation 1. By using keys, select the “Adjustment” setting. ［ Measurement ］ ［ Application ］ 1 Short Brown ［ Display ］ ［ Adjustment ］ Serial number ［ Time ］ AB0 1 234 ［ Communication ］...
-
Page 19: Automatic Adjustment Mode
(2) Automatic adjustment mode Operation Display Explanation 1. By using keys, select the “Adjustment” setting. ［ Measurement ］ ［ Application ］ 1 Short Brown ［ Display ］ ［ Adjustment ］ Serial number ［ Time ］ AB0 1 234 ［ Communication ］... - Page 20 Operation Display Explanation 4. After confirming both composition ［Adjustment］Application 1 Short Brown N e v e r o p e n t h e c o v e r d u r i n g values are correct, and press the Measurement. Measurement in progress... key.
-
Page 21: Time Settings
7. Time settings Operation Display Explanation 1. By using keys, select the “Time” setting. ［ Measurement ］ ［ Application ］ 1 Short Brown ［ Display ］ ［ Adjustment ］ Serial number ［ Time ］ AB0 1 234 ［ Communication ］... -
Page 22: Communication
8. Communication Operation Display Explanation 1. By using keys, select the “Communication” setting. ［ Measurement ］ ［ Application ］ 1 Short Brown ［ Display ］ ［ Adjustment ］ Serial number ［ Time ］ AB0 1 234 ［ Communication ］... -
Page 23: Replacment For Lamp
9. Replacment for lamp AN-820 uses tangsten lamp as an optical power. In case that lamp goes defective, replace lamp according to the following procedure. Operation Display Explanation 1. Turn the power switch “OFF”. [ ] means, turn [OFF] 2. Remove cover behind main body by loosing two screws. -
Page 24: Cleaning
10. Cleaning When the surface of AN-820 is found dirty, wipe it by soft cloth. If extremely dirty, wipe with wet cloth. Note : Do not use any volatile chemicals such as a thinner or benzene. Note : While measurement is in progress, some grain sample may be spilt out and is dropping on the tray of the bottom of AN-820. -
Page 25: Appendix> Guidelines For Using An-820 With Maximum Accuracy
More than half a day before performing the measurements, take standard sample out of the cold, dark area and put it in the same environment as AN-820. After the sample returns to normal temperature, perform measurements. Measure the standard sample 3 or 5 times, find th average values for each composition, and then compensation of each. - Page 28 0904・AI・0101・030_S...
