NOTE: This one-page document is intended only as a quick reference for installation – please read
the SP Controls Application Note for a complete description of this projector driver prior to installation.
I. Driver Features

1. Input Selection Mapping

Selection 1:
VIDEO
Selection 2:
S-VIDEO
Selection 3:
RGB 1
Selection 4:
RGB 2

2. Hidden Function Mapping (Default Configuration)

Using the ON button as a shift key, press the following buttons to access the specified projector features.
Selection 1:
AUTO IMAGE
Selection 2:
MUTE
Selection 3:
ADJ LEFT
Selection 4:
ADJ RIGHT
Off:
MENU
Volume Up:
ADJ UP
Volume Down:
ADJ DOWN

3. Other Driver Features

Power Status Feedback Method
Control Wiring:
II. Wiring Specifications
NOTE: For a wiring diagram, please see the SP Controls Application Note following this document.
1. RS-232:
Wire the Panel RS-232 port to a female DB9 as follows:
TX to
2
RX to
3
GND to
5
Connect this female DP9 to the projector port labeled CONTROL.
2. Infrared Emitter:
Wire the Panel IR/Serial port to a female 1/8" Mini as follows:
IR/SER to
tip
GND to
ring
Connect to the included IR Emitter and attach the emitter bud to any projector IR window.
04/12/05
RS-232 Power Polling
RS-232 and IR-Emitter
SP Controls reserves the right to modify specifications without notice at any time.
Quick Start Reference Sheet
ViewSonic PJ862
Revision A
