- Page 1 VACUUM TUBE INTEGRATED AMPLIFIER SQ-N150 Owner`s Manual...
-
Page 2: Table Of Contents
Contents Precautions ············································································································· 1 Features of This Unit ································································································ 2 Names and Functions ······························································································ 3 Connections ············································································································ 6 Operations ··············································································································· 8 How to Use Remote Control ···················································································· 9 Block Diagram ······································································································· 10 Specifications ········································································································ 11 Before Asking for Repair Service ············································································ 12... -
Page 3: Precautions
Precautions VACUUM TUBE INTEGRATED AMPLIFIER SQ-N150 Installation place Cautions in connecting speakers Install this unit in a location where good ventilation and heat When making speaker system connections, exercise extra radiation are assured. care not to short-circuit between (+) and (–) of the speaker Especially, installation of this unit where direct sunlight is terminals and speaker input terminals of this unit. -
Page 4: Features Of This Unit
Headphone output terminal This terminal allows you to casually enjoy sound with head- phones. Selector switch IC Selector switch IC of high sound quality, which is used in LUXMAN top-end control amplifier, C-900u, improves the separation and crosstalk performances. -
Page 5: Names And Functions
Names and Functions VACUUM TUBE INTEGRATED AMPLIFIER SQ-N150 Front panel 1. Operation switch (OPERATION) Caution: Toggles the power on and off. Before pulling out the plug, be sure that the volume control is at When wiring or connection is performed, be sure to turn off a low level to prevent loud sound from coming out of speakers this switch. - Page 6 Names and Functions Top view 10. Input selector (INPUT SELECTOR) 12. Tone control for treble (TREBLE) Selects an input device from the devices such as a CD play- Controls the frequency characteristics of the high-frequen- er, an SACD player, and a tuner connected to each input cy range.
- Page 7 VACUUM TUBE INTEGRATED AMPLIFIER SQ-N150 Rear panel 14. Signal ground terminal 17. Speaker terminals (SPEAKERS) (SIGNAL GROUND) Connects a speaker system. The right speaker terminal shall be connected to the right A signal ground terminal for devices to be connected to this side (R), and the left speaker terminal shall be connected to unit.
-
Page 8: Connections
Connections CD PLAYER ANALOG PLAYER – – SPEAKER SYSTEM... - Page 9 VACUUM TUBE INTEGRATED AMPLIFIER SQ-N150 Before connecting How to connect a CD player, SACD player, D/A converter, tuner, or other devices Before connecting other devices, connect the jack side of the accessory power cable to the AC inlet of this unit.
-
Page 10: Operations
Operations Before operation Balance control 1. Ensure that the connections are correctly made. (Normal The balance control allows users to adjust the balance of playback cannot be achieved with wrong connections of sound volume between right and left channels. R, L, !, or @.) When the balance adjustment is not required, the balance 2. -
Page 11: How To Use Remote Control
How to Use Remote Control VACUUM TUBE INTEGRATED AMPLIFIER SQ-N150 Accessory remote control (RA-25) Remote control The remote control shall be aimed at the remote sensor of this unit within the specified angle range shown in the illus- tration. 30°... -
Page 12: Block Diagram
Block Diagram... -
Page 13: Specifications
Specifications VACUUM TUBE INTEGRATED AMPLIFIER SQ-N150 Rated output 10 W+10 W (6 Ω) Total harmonic distortion Less that 1 % (1 kHz, 10 W/6 Ω, LINE STRAIGHT “ON”) Input sensitivity/input impedance PHONO (MM) : 3.0 mV/47 kΩ PHONO (MC) : 0.33 mV/100 Ω... -
Page 14: Before Asking For Repair Service
While in use, this unit may display phenomena which may be confused as malfunctions. Before contacting your country’s official LUXMAN distributor for repair services, please read the operating instructions and operating instructions for any connected input and through output devices and check the troubleshooting table below. If the cause of the malfunction cannot be identified, please con- tact your dealer. - Page 16 LUXMAN CORPORATION, JAPAN AG00987E81A 1-3-1 Shinyokohama, Kouhoku-ku, Yokohama-shi, Kanagawa 222-0033, Japan Printed in Japan...
