Citrix NetScaler SDX 8015 Manual page 232

Voltage 7 (Volts)
Fan 0 Speed (RPM)
Fan 1 Speed (RPM)
Fan 2 Speed (RPM)
Fan 3 Speed (RPM)
Temperature 0 (Celsius)
Temperature 1 (Celsius)
Temperature 2 (Celsius)
Temperature 3 (Celsius)
Done
7. Run the following command to generate a tar of system configuration data and statistics: show techsupport
Example
> show techsupport
showtechsupport data collector tool - $Revision: #1 $! NetScaler version 9.2
The NS IP of this box is 10.10.10.10
Current HA state: Primary (or this is not part of HA
pair!)
All the data will be collected under
/var/tmp/support/collector_10.10.10.10_P_13May2011_12_01
Copying selected configuration files from nsconfig ....
Note: T he output of the command is available in the /var/tmp/support/collector_<IP_address>_P_<date>.tar.gz file.
Copy this file to another computer for future reference. T he output of the command might be helpful in the event that
you want to contact Citrix T echnical Support.
8. At the NetScaler command line interface, switch to the shell prompt. T ype: shell
9. Run the following command to verify that 2 Cavium cards are available: root@ns# dmesg | grep cavium
Example
root@ns# dmesg | grep cavium
Cavium cavium_probe : found card 0x177d,device=0x11
cavium0 mem 0xddd00000-0xdddfffff irq 24 at device 0.0 on pci20
Cavium cavium_probe : found card 0x177d,device=0x11
cavium1 mem 0xd6f00000-0xd6ffffff irq 32 at device 0.0 on pci5
Run the following command to verify that 596 MB of RAM is reserved for shared memory: root@ns# dmesg | grep
memory
Example
root@ns# dmesg | grep memory
real memory = 52613349376 (50176 MB)
avail memory = 49645355008 (47345 MB)
NS-KERN map_shared_mem_ioctl (cpu 7, NSPPE-03): Reserving 596 MB for shared memory type 0
10. Run the following command to verify that the appliance has 12 CPU cores: root@ns# dmesg | grep cpu
Example
root@ns# dmesg | grep cpu
cpu0 (BSP): APIC ID: 0
https://docs.citrix.com
0.00
5929
0
0
0
40
35
0
0
© 1999-2017 Citrix Systems, Inc. All rights reserved. p.235
