- Page 1 Citrix NetScaler Quick Start Guide: MPX 25100 40G, MPX 25160 40G Platform Citrix NetScaler 10.1, 10.5...
- Page 2 XenApp, XenAppliance, XenCenter, XenClient, XenDesktop, XenEnterprise, XenServer, XenSource, Xen Data Center, and Zenprise are trademarks of Citrix Systems, Inc. and/or one of its subsidiaries, and may be registered in the U.S. Patent and Trademark Office and other countries. Other product and company names mentioned herein may be trademarks of their respective companies.
-
Page 3: Table Of Contents
Citrix NetScaler Quick Start Guide: MPX 25100 40G, MPX 25160 40G Platform Contents Quick Installation and Configuration ......................4 Before you Begin ............................4 Citrix NetScaler MPX 25100 40G, MPX 25160 40G.................. 4 Configuration Requirements ........................6 Installation ..............................7 Rack Mounting the Appliance ....................... -
Page 4: Quick Installation And Configuration
Citrix NetScaler MPX 25100 40G, MPX 25160 40G The Citrix NetScaler MPX 25100 40G, MPX 25160 40G are 2U appliances. Each model has two 10-core processors, 256 gigabytes (GB) of memory, four 40G QSFP+ ports, and sixteen 10G SFP+ ports (4x40G QSFP+ + 16x10G SFP+). - Page 5 Citrix NetScaler Quick Start Guide: MPX 25100 40G, MPX 25160 40G Platform The NetScaler MPX 25100 40G, MPX 25160 40G appliances have the following ports: RS232 serial Console Port. 10/100Base-T copper Ethernet Port (RJ45), also called the LOM port. You can use this port to remotely monitor and manage the appliance independently of the NetScaler software.
-
Page 6: Configuration Requirements
Two power supplies, each rated at 1000 watts, 100-240 volts. Each power supply has an LED that indicates the status of the power supply, as described in http://docs.citrix.com/en-us/netscaler/10-1/ns-gen-hardware-wrapper-10-con/ns- hardware-common-components-ref.html. Disable alarm button, which is functional only when the appliance has two power supplies. -
Page 7: Installation
The appliance is shipped with rack-rail hardware. This hardware consists of two inner rails that you attach to the appliance, one on each side, and a rack-rail assembly that you attach to the rack. The following figure illustrates the steps involved in mounting the Citrix NetScaler appliance to a rack. -
Page 8: Connecting A Netscaler Appliance To The Network
Connect the interfaces on the appliance to the network ports on the appropriate switches by using Ethernet/fiber optic cables. Figure 4. Connecting a Citrix NetScaler appliance to the network Warning: Connecting multiple network ports to the same switch or VLAN can result in a... -
Page 9: Connecting An Appliance To A Power Source
If your appliance has more than one power supply, repeat this process. The extra power supply serves as a backup. The Citrix logo and the LCD on the front of the NetScaler illuminate after the appliance starts, and the LCD indicates the operational status of the appliance. -
Page 10: Installing 40G Active Optical Cables Or Cr4 Direct Attach Cables
AOCs are compliant with QSFP MSA high-density form factor. CR4 cables are compliant with QSFP+ MSA high-density form factor. Citrix NetScaler 40G MPX 14000 series and 40G MPX 25000 series appliances support 40 Gbps parallel active optical cables and passive CR4 cables in lengths of 1, 3 or 5 meters. -
Page 11: Setting Up Connectivity
Citrix NetScaler Quick Start Guide: MPX 25100 40G, MPX 25160 40G Platform Note: Illustrations in the figures are only for reference and might not represent the actual I/O configuration of your NetScaler appliance. 2. To remove an AOC or a CR4 cable, gently pull the tab on the top of the cable, then remove from the port, as shown in the following figure. -
Page 12: Using The Netscaler Serial Console
To configure the appliance by using the configuration utility 1. Connect the appliance to a management workstation or network. 2. Open a browser and type: http://192.168.100.1 Note: The NetScaler is preconfigured with the IP address 192.168.100.1. 3. In the User Name box, type nsroot. 4. -
Page 13: Lcd Keypad Setup
Citrix NetScaler Quick Start Guide: MPX 25100 40G, MPX 25160 40G Platform set system user nsroot -password Enter password: ***** Confirm password: ***** save ns config reboot Note: For information about deploying a high availability (HA) pair, see http://docs.citrix.com/en-us/netscaler/10-1/ns-system-wrapper-10-con/ns-nw-ha-intro-wrppr- con.html. -
Page 14: Power Cycling The Appliance
System Specifications The following table summarizes the specifications of the NetScaler MPX 25100-40G and MPX 25160-40G appliances. Specifications MPX 25100 40G, MPX 25160 40G Regulatory model number Citrix 2U1P1D Processors 2 ten-core Memory 256 GB Number of power supplies AC power supply input voltage,... -
Page 15: Additional Information
A complete set of documentation is available from http://docs.citrix.com/. To contact Citrix Support, call 1-800-4-CITRIX (1-800-424-8749), or log on to MyCitrix at http://www.citrix.com. You will be asked for your hardware serial number as part of the support process. Detailed instructions for contacting support can be found at: http://citrix.com/site/resources/dynamic/sup2nd/Citrix_HWS_SerialNO.pdf.
