- Page 1 SLR-B Solar CCTV Series Installation Manual Version: VIPSLRB-Q219...
- Page 2 1. Pre-Install Information Thank you for purchasing a SLR-B Series Solar Surveillance System. This install guide covers basic setup, installation and use of your surveillance system. For more information, please visit: www.vip-vision.com VIP Vision SLR-B Solar Surveillance Installation Manual - Version: VIPSLRB-Q219...
-
Page 3: Included Components
1.1 Included Components Part Product Code Image SSL-B50MN (50W) Solar Panel (w/ remote control device) SSL-B60MN (60W) 4.0MP Mini PTZ Dome Camera VSIP4MPPTZMINI Camera Adapter VSBKTA106 Right Angle Bracket VSBKTB305W Junction Box VSBKTA140 Pole Mount Bracket VSBKTA150 128GB microSD card MICROSD128GB Ubiquiti 5.8GHz 120°... -
Page 4: Camera Information
Encoding Method Variable Bit Rate Encoding Method Constant Bit Rate Quality 6 (Best) Bit Stream 512Kbps Ref Stream 1536-8192Kbps Ref Stream 139-768Kbps I Frame Interval I Interval Watermark 1 (off) VIP Vision SLR-B Solar Surveillance Installation Manual - Version: VIPSLRB-Q219... - Page 5 1.3 Solar Panel Information Motion Sensing Solar Panel with 50W Street Light Note: This solar panel system is fitted with undervoltage protection, which disconnects the load at approximately 10.8V. If you are not receiving any voltage on the output wires, place the panel in direct sunlight for a minimum of one hour and re-test.
- Page 6 1.3 Solar Panel Information (continued) Solar Panel Dimensions Solar Panel Assembly Diagram Lamp Body Bird Spikes VIP Vision SLR-B Solar Surveillance Installation Manual - Version: VIPSLRB-Q219...
-
Page 7: Installation
2. Installation 2.1 Mounting the Solar Panel to the Pole Caution: Solar panel must be placed so it is in direct sunlight all day. Any shading will greatly reduce the solar panel’s performance! 1. Drill an 8mm hole in the pole (minimum 15cm down from the top of the pole) on the same side that the camera will be mounted. - Page 8 Solar panel angle adjust cover Solar panel angle adjust Allen head 3. Tighten the bolt after adjusting the angle to secure the solar panel in place. 4. Replace the cover. VIP Vision SLR-B Solar Surveillance Installation Manual - Version: VIPSLRB-Q219...
- Page 9 2.3 Mounting the Camera to the Pole The camera, camera adapter, right angle bracket and junction box are already connected (A, B, C & D). • Mount the pole mount bracket to the pole first. • After the pole mount is installed, mount the junction box to the pole mount. •...
- Page 10 Note: The 3 included band clamps are 65-89mm for poles 50-60mm in diameter. If installing on a thicker pole (eg. 80-150mm), larger band clamps will be required. Fig. 2.3a Fig. 2.3b Mounted pole bracket (front) Mounted pole bracket (back) VIP Vision SLR-B Solar Surveillance Installation Manual - Version: VIPSLRB-Q219...
- Page 11 2.3 Mounting the Camera to the Pole (continued) 2. Open the junction box (Fig. 2.3c). Fig. 2.3c Junction box interior (no 4G router) Note: This image shows the inside of the junction box as seen with the WiFi kit. The 4G kit will also have the 4G router pre-installed inside the junction box.
- Page 12 5. Carefully connect the solar panel power cable to the terminal block, with the red wire connecting to + and the black wire connecting to -. (Fig. 2.3f) Fig. 2.3e Terminal block Fig. 2.3f Solar battery cables connected to terminal block VIP Vision SLR-B Solar Surveillance Installation Manual - Version: VIPSLRB-Q219...
- Page 13 3. Connections 3.1 Connect using WiFi [SLR-B120/180-4W] This section covers how to set up the WiFi network for your WiFi Solar Kit. Most of the setup for the solar panel side of the installation has already been done - it just needs to be connected to the solar panel battery for power.
- Page 14 Wireless Bridge (AP) Camera Wireless Bridge 240VAC (Station) Power 24V PoE Injector DO NOT USE 802.3ac (48V) PoE Injector Network Switch Router (optional) NVR (optional) Internet Fig. 3.1a Example WiFi Setup VIP Vision SLR-B Solar Surveillance Installation Manual - Version: VIPSLRB-Q219...
- Page 15 3.2 Connect using 4G [SLR-B120/180-4G] NOTE: 4G setup requires an active SIM card (not included). For more information on how to configure the 4G router, refer to the 4G router manual (included). 1. Insert an active SIM card into the SIM slot. 2.
- Page 16 3.2 Connect using 4G [SLR-B120/180-4G] (continued) Camera & 4G router connected via RJ45 4G router powered via terminal block Camera powered via terminal block Battery/terminal block connection Fig. 3.2b Connection overview VIP Vision SLR-B Solar Surveillance Installation Manual - Version: VIPSLRB-Q219...
- Page 17 3.2 Connect using 4G [SLR-B120/180-4G] (continued) QR code remote access setup (4G) Internet access is reuiqres for remote access setup. 1. Install the free app from the App Store for iOS (iDMSS Plus) or Play Store for Android (gDMSS Plus). 2.
- Page 18 3.3 Finish Camera Installation Close the junction box and securely fasten the 4 attached bolts (Fig. 3.3a). Fig. 3.3a Complete solar surveillance system VIP Vision SLR-B Solar Surveillance Installation Manual - Version: VIPSLRB-Q219...
- Page 19 CCTV system. Incorrectly editing power settings can permanantly damage the solar panel, solar battery and/or LED light. Consult your VIP Vision professional for more information. Only edit power settings exactly as outlined in this guide. Understanding Settings: Before adjusting solar panel settings, familiarise yourself with the setting definitions below: 1.
-
Page 20: Default Settings
The device number for this system is: PCC_G05 3. Press and hold the ON button to enable the solar light. Fig. 4.3a Fig. 4.3b Solar panel remote control Remote control LCD VIP Vision SLR-B Solar Surveillance Installation Manual - Version: VIPSLRB-Q219... - Page 21 4.3 Remote Control (continued) Press to power on. Press and hold for 2 seconds, then Power release to power off the remote control. Scroll Up Press to scroll up. Scroll Down Press to scroll down. Controller On Press and hold to enable the LED light control. Controller Off Press and hold to disable the LED light control.
- Page 22 To lock/Unlock the remote control, press the Test, Enter and Back buttons together. If you hear a single beep, the remote is locked. If you hear three beeps, the remote is unlocked. VIP Vision SLR-B Solar Surveillance Installation Manual - Version: VIPSLRB-Q219...
-
Page 23: Troubleshooting
5. Troubleshooting I can't connect to the camera using the QR code. • Ensure that your camera is powered on power. • Check that the inserted SIM card is active. Video footage is slow/laggy/choppy. • Ensure that your camera is in an area with good mobile service coverage and that only one user is viewing the system at once. - Page 24 Version: VIPSLRB-Q219 Note: All products, designs and software here are subject to change without prior written notice.
