miniIPS Operating Manual
Document Ref:
0760824b
Date:
August 2019
This document was prepared by the staff of Valeport Limited, the Company, and is the property of the
Company, which also owns the copyright therein. All rights conferred by the law of the copyright and by
virtue of international copyright conventions are reserved to the Company. This document must not be
copied, reprinted or reproduced in any material form, either wholly or in part, and the contents of this
document, and any method or technique available therefrom, must not be disclosed to any other person
whatsoever without the prior written consent of the Company.
Valeport Limited
St Peters Quay
Tel:
Totnes
e mail:
Devon, TQ9 5EW
Web:
United Kingdom
As part of our policy of continuous development, we reserve the right to alter, without prior notice, all
specifications, designs, prices and conditions of supply for all our equipment.
Operating Manual
+44 1803 869292
sales@valeport.co.uk | support@valport.co.uk
www.valeport.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the miniIPS and is the answer not in the manual?

Questions and answers

Related Manuals for Valeport miniIPS

Summary of Contents for Valeport miniIPS

  • Page 1 Date: August 2019 This document was prepared by the staff of Valeport Limited, the Company, and is the property of the Company, which also owns the copyright therein. All rights conferred by the law of the copyright and by virtue of international copyright conventions are reserved to the Company. This document must not be...

  • Page 2: Table Of Contents

    5.2.6 Information #Codes ............................ 13 5.2.7 Calibration ............................ 13 6. Electrical ............................. 14 6.1. Wiring Information ............................ 14 7. Software ............................. 15 8. Care & Maintenance ............................. 16 9. Ordering and Part Numbers ............................. 17 Page 2 © 2019 Valeport Ltd...

  • Page 3: Eu Declaration Of Conformity - Ce Marking

    1. EU Declaration of Conformity - CE Marking Any changes or modifications to the product or accessories supplied, that are not authorised by Valeport Ltd, could void the CE compliance of the product and negate your authority to operate it. This product has demonstrated CE compliance under conditions that include the use of shielded cables.

  • Page 4: Introduction

    0760824b - miniIPS Operating Manual 2. Introduction The Valeport miniIPS “Intelligent Pressure Sensor” is designed to measure water pressure and provide a real time output of that data. Suitable for use in a variety of subsea applications (ROV’s, construction, monitoring, positioning), one of the key development drivers was to provide a cost effective alternative to the use of resonant quartz pressure sensors.

  • Page 5: Sensors

    Sensors 3. Sensors Pressure The miniIPS is fitted with the following sensors: · A high accuracy (0.01%), temperature compensated piezo-resistive pressure transducer Type: Strain Gauge Range: 5, 10, 30, 50, 100, 300 or 600 Bar (factory fit option) Resolution: 0.001% of full range Accuracy: ±0.01% or full range...

  • Page 6: Physical Characteristics

    0760824b - miniIPS Operating Manual 4. Physical Characteristics 4.1. Materials Housing & Bulkhead: Titanium Sensor Cap: Acetal Transducer Diaphragm Stainless Steel Connector: Standard is SubConn type MCBH6F (titanium) Alternatives may be supplied on request Weight: <1kg (in air) 4.2. Dimensions Please refer to factory for detailed dimensions if required.

  • Page 7: Communications

    Communications 5. Communications 5.1. Welcome Message When power is applied to the miniIPS, it will normally output a welcome message as follows, detailing the software version: You are connected to a Valeport Mini IPS Sensor 0760700B 14/09/2019 07:00 Copyright 2019 #209;OFF (or ON)

  • Page 8: Communications Setup

    #002 Responds with current sensor address #005;ON (or OFF) Turns the miniIPS address mode on (or OFF). In address mode, the sensor will only respond to commands prefixed by its address, or the global address “00”. Example: 03:#028 Sensor address “03” begin sampling...
  • Page 9 Note: that the last value (shown in italics) must be included, even though it is not part of the definition of Fixed Averaging. It does not matter what values is used here, provided it fits within the general constraints defined above (1 to 120 etc.). Page 9 © 2019 Valeport Ltd...

  • Page 10: Pressure Tare

    0760824b - miniIPS Operating Manual 5.2.4. Pressure Tare The pressure sensor fitted to the miniIPS measures absolute pressure, i.e. it includes atmospheric pressure. The pressure tare function allows the atmospheric pressure (as measured by the sensor before deployment) to be removed from the readings, so the output is simply pressure of water.

  • Page 11: Data Output Formats

    The default output units for the miniIPS are deciBar (dBar), equivalent to 0.1Bar, or approximately 1m of seawater. The miniIPS can also output pressure in PSI. It is also possible to present the data in units of metres or feet of seawater, calculated using the UNESCO Simple Pressure / Depth relationship, which assumes “standard”...
  • Page 12 0760824b - miniIPS Operating Manual 5.2.5.4. NMEA Format Command: #013;NMEA Format: $PIPS,0009.91, M*78 Notes: NMEA Identifier, Output Data, Units + Checksum Last three characters are a checksum 5.2.5.5. HYPACK Format Command: #013;HYPACK Format: 009.9 0000.0 Notes: Output Data + Spare field 5.2.5.6.

  • Page 13: Information #Codes

    Note that not all of these codes are covered by this manual – use this feature with care. 5.2.7. Calibration The miniIPS may be returned to Valeport or one of its approved laboratories for recalibration, or it may be re- calibrated by the customer using a Class A deadweight tester, or defined standard of the customer’s choosing.

  • Page 14: Electrical

    0760824b - miniIPS Operating Manual 6. Electrical Power 9 – 28V DC input (isolated) Draws approximately 40mA at 12vDC Output Units are fitted with both RS232 and RS485 communications as standard. RS485 is enabled by grounding a pin in the communications lead (refer to Section 4). Protocol is 8 data bits, 1 stop bit, no parity, no flow control.

  • Page 15: Software

    Software 7. Software The miniIPS is fully compatible with Valeport Datalog X2 and Terminal X2. These can be downloaded from Valeport's website. Page 15 © 2019 Valeport Ltd...

  • Page 16: Care & Maintenance

    0760824b - miniIPS Operating Manual 8. Care & Maintenance The miniIPS is remarkably robust, being primarily constructed of titanium. The only maintenance required, other than periodic recalibration as necessary, is to keep the sensor as clean as possible. · After deployment, remove the outer acetal sensor cap.

  • Page 17: Ordering And Part Numbers

    (SubConn part MCBH6F - Specify Titanium) Housed system 0.5m pigtail (SubConn parts MCIL6M and MCDLSF) 0652EA1 Fitted with: · 4mm bunch pins for power · 9 pin D type for communications. 0760002 Calibration adapter fitting Page 17 © 2019 Valeport Ltd...
