UV-SVP
Operating Manual
+44 1803 869292
sales@valeport.co.uk | support@valport.co.uk
www.valeport.co.uk
Advertisement
Related Manuals for Valeport UV-SVP
Summary of Contents for Valeport UV-SVP
- Page 1 28 September 2018 This document was prepared by the staff of Valeport Limited, the Company, and is the property of the Company, which also owns the copyright therein. All rights conferred by the law of the copyright and by virtue of international copyright conventions are reserved to the Company.
-
Page 2: Table Of Contents
1. EU Declaration of Conformity - CE Marking ............................. 3 2. Introduction ............................. 5 3. Specifications ............................. 6 4. Data Requests ............................. 9 5. Output Format ............................. 11 6. Dimensions ............................. 12 7. Wiring Information ............................. 13 © 2018 Valeport Ltd Page 2... -
Page 3: Eu Declaration Of Conformity - Ce Marking
EU Declaration of Conformity - CE Marking 1. EU Declaration of Conformity - CE Marking Page 3 © 2018 Valeport Ltd... - Page 4 Please note: Any changes or modifications to the product or accessories supplied, that are not authorised by Valeport Ltd, could void the CE compliance of the product and negate your authority to operate it. This product has demonstrated CE compliance under conditions that include the use of shielded cables.
-
Page 5: Introduction
Valeport Terminal or HyperTerminal. The instrument is based on Valeport’s existing “mini” sensor range and has been designed to be simple to use and maintain, as well as being small and lightweight for easy handling and deployment. -
Page 6: Specifications
06508142b - UV-SVP 3. Specifications Dimensions: Housing Ø Mounting bulkhead Ø Overall length Weight in Air 63mm 90mm 139mm 0.726 Kg Materials: Part Material Main housing Titanium Sensor bulkhead Titanium Connector Titanium SubConn MCBH6F Right Angle Sound Velocity Carbon Composite legs, Titanium Body, Ceramic Transducer behind... - Page 7 The material selected does not measurably expand over the operating temperatures of the instrument, ensuring the highest possible accuracy at all times. Digital Sampling Technique: Page 7 © 2018 Valeport Ltd...
- Page 8 06508142b - UV-SVP Enables a timing resolution of 1/100th of a nanosecond, equivalent to about 0.5mm/sec speed of sound on a 25mm path sensor, or 0.125mm/sec on a 100mm sensor. In practice, the output is restricted to 1mm/sec resolution. Linear sensor performance allows easy calibration.
-
Page 9: Data Requests
The instrument responds to a series of text commands that are detailed below for those users who wish to interface the UV-SVP to other systems. This list is not comprehensive, but will allow the standard functions of the instrument to be accessed. - Page 10 06508142b - UV-SVP Code Followed By Operation #034 <CR> Returns the units serial number #039 ;ModeValue<CR> Set mode without putting unit into run mode Where M1 = 1 Hz continuous output M2 = 2 Hz continuous output M4 = 4 Hz continuous output...
-
Page 11: Output Format
The temperature data is given to 3 decimal places. Value is in °C and leading zeroes are included; signed if negative: - 21.456 - 02.769 - -01.174 · Sound Velocity is given in m/s, as a fixed length string with 3 decimal places. In air, the sensor reads 0000.000 Page 11 © 2018 Valeport Ltd... -
Page 12: Dimensions
06508142b - UV-SVP 6. Dimensions © 2018 Valeport Ltd Page 12... -
Page 13: Wiring Information
RS232 GND 5 (Link to 1,6,8,9) RS232 Tx (Out of sensor) or RS485A RS232 Rx (Into sensor) or RS485B Red Plug Link to Pin 1 for RS485. N/C for RS232 Power GND Black Plug Page 13 © 2018 Valeport Ltd...
