Summary of Contents for Bushranger 7101E-RIDER
- Page 1 Rechargeable Ride-On Lawnmower 7101E-RIDER Lithium Polymer battery equipped OPERATOR’S MANUAL...
-
Page 2: Table Of Contents
Owner’s Manual, contact your local OPERATING CONTROLS ..........13 Bushranger Dealer. If you need help locating a dealer, Switches and Buttons ............ 13 please contact the Bushranger Customer Support Power level indicator ............ -
Page 3: General Safety Warning
Owner’ s responsibility and are not covered by this Limited Warranty: Adjustments after the first (30) thirty days of purchase. The mower must be returned to the Bushranger dealer outlet of purchase within the first 30 days of purchase, so as the required adjustments on the mower can take place. - Page 4 GENERAL RIDE-ON MOWER SAFETY WARNINGS WARNING Read all safety warnings, instructions, illustrations and specifications provided with this ride-on lawnmower. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “ride-on lawnmower”...
- Page 5 Have your ride-on lawnmower serviced by a Bushranger qualified repair outlet using only genuine Bushranger replace ment parts. This will ensure that the safety of the ride-on lawnmower is maintained. Never service damaged battery packs. Service of battery packs should only be performed by the manufacturer.
- Page 6 General hazard safety alert. Beware of thrown or flying objects to bystanders. Read instruction manual. Keep bystanders away from the machine. 15 m (50 ft) Beware electric shock hazard. Keep supply flexible cord away from cutting means. Keep hands and feet away from the blades. Wait until all machine components have &...
-
Page 7: Safety Regulations
• Keep hands and feet away the enclosure. manual. Be thoroughly familiar with the controls and the • Worn parts should be referred to your Bushranger proper use of the machine before starting operations. service centre. • Before using the machine, inspect the machine by... -
Page 8: Slope Operation
SLOPE OPERATION IV. GENERAL INSTRUCTIONS Mowing on banks can be dangerous: FOR WORKING WITH YOUR • Slopes are a major factor related to slip and fall LAWNMOWER accidents, which can result in severe injury. All slopes require extra caution. If you feel uneasy on a slope, •... -
Page 9: Customer Responsibilities
• PROPER USE Switch on the motor carefully according to instructions • and with feet well away from the blades. The electric riding mower is for private use. The mower • Rotating blades can cut off legs and arms and are may only be used for the maintenance of grass or lawns capable of throwing objects. -
Page 10: Specification
SPECIFICATIONS PRODUCT NAME Rechargeable Ride-on Lawnmower COMMERCIAL NAME E-RIDER TYPE BATTERY POWERED MODEL 7101 Warranty 2 year limited non commercial Battery Warranty 2 year limited non commercial Drive Motor Forward--Neutral--Reverse Drive system Electric Battery Capacity- Volts & Amp hour Rating 72V/18AH battery Ground Speed (approx.) Forward Max.3.7 mph, Reverse Max.3.1 mph... -
Page 11: Features And Controls
Carefully remove the machine from its packaging and check that you have all the following items: Rider-on Lawnmower Operating manual When parts are missing or damaged, please contact your Bushranger dealer. Not all of the accessories illustrated or described are included as standard delivery . FEATURES AND CONTROL... -
Page 12: Assemblies & Set Up
Charge the 72V lithium polymer battery for 8-10 hours to ensure a full charge. Carefully read Operator’s Manual or ask your local Bushranger dealer for details. Charging should be carried out in the ideal surrounding temperature from 0 to 40°C. -
Page 13: Grass Deflector Installation
Grass Deflector Installation - Fig 3 • Remove and dispose any packaging. • The mowing deck can be shifted from mode “mulching” to “discharging” • Press down the lever A to unlock and turn upper side to open the cover B of discharging opening , and then carefully insert the discharging deflector and make it catch the slots under the cover. -
Page 14: Using Parking Brake
Press the button Using Parking Brake Brake - Fig 6 in for release • To Lock the parking brake, lever location is up. • To Unlock the parking brake, lever location is down. Result: The parking brake prevents the machine from moving. -
Page 15: Recharging The Mower
Recharging the mower • When battery power is poor, the power lever indicator will flash, which means the unit need charging the battery. • Charging should be carried out in the ideal surrounding temperature from 0 to 40°C. • Make sure the ignition key is in the off position. •... -
Page 16: Adjusting Cutting Height
Disconnecting the Charger Remember to disconnect the charger from the machine using this sequence: Pull the plug from the charger out of the wall outlet. Slide back the button C and turn the plug counter-clockwise, and then pull the plug from the plug from the socket to disconnect the charger from the machine. -
Page 17: Operating Riding-Mower
OPERATING RIDE-ON MOWER Operating REVIEW THIS CAREFULLY TO ENSURE SAFE AND LASTING OPERATION Please ensure that the mower has been fully charged before beginning. That involves connecting the charger plug to the mating socket if the battery is running low (Fig 10.3). Then plug the other end of the charger into a standard wall outlet. -
Page 18: Mowing Tips
23. Release the accelerator to come to a complete stop. Then move the switch on the drive control switch to the forward arrow position (Fig 4.1). 24. To reengage the blades follow step 9. Use the accelerator pedal to begin the forward motion once again. 25. -
Page 19: Maintenance And Servicing
MAINTENANCE AND SERVICING Tire Tire Sizes: Front (2) - 11x4.00-5 Back (2) - 13x5.00-6 WARNING: Never exceed the maximum inflation pressure shown on the sidewall of the tire! • Keep tires free of gasoline, oil, or insect control chemicals which can harm rubber. •... -
Page 20: Rear Maintenance
Use block of wood between blade and mowing deck and then tighten the blade nut, turning clockwise. TO SHARPEN BLADE NOTE: We do not recommend sharpening blade by users for safety reasons, please contact local Bushranger dealer for replacing new blades. -
Page 21: Storage
Battery replacement When the battery pack is on the end of life, please contact the local Bushranger dealer to replace the battery pack. The dealer will collect the old batteries separately and sent them to the specialized agencies for environmentally-friendly treatment. -
Page 22: Trouble Shooting
TROUBLE SHOOTING SYMPTOM POSSIBLE CAUSE TREATMENT No power Seat OPC switch "off' or damaged Sit down on seat or Check and change switch. Drive mode switch or key switch damaged Check and change. Drive controller damaged Check and change. Poor contact of wire bundle plugs Check and change. -
Page 23: Warranty
WARRANTY Warranty Conditions Australian Consumer Law (REG. 90): The benefits to the consumer given by this warranty are in addition to other rights and remedies of the consumer under a law in relation to the good or services to which this warranty relates. - Page 24 Copyright © 2019 Roy Gripske and Sons Pty. Ltd. All rights reserved. # 1124725541843643. Images are for illustrative purposes only. Bushranger is a trademark of Roy Gripske & Sons Pty Ltd. PLP shall not be liable for technical or editorial errors ®...
