• REMOTE POWER STEER Mode:
With a hand remote, panel remote, steering lever or steering wheel
station installed, this will allow control of rudder position from the
remote station.
• RUDDER and RESPONSE Settings:
These customise the AP55 Autopilot for your vessel's steering.
They may also be used to adjust for varying sea conditions.
• Compass Calibration:
The AP55 compass can be calibrated on the vessel using a simple
procedure.
• Rudder Angle Displays:
The AP55 Display Unit LCD can be set to display the rudder angle
as a numeric number.
• Selectable backlighting:
When using the autopilot at night, the backlighting can be turned on.
