AUTO Mode

• Press the AUTO button. AUTO mode will be selected. A beep will
sound and the text display will change to "A***". The Auto LED
will light
The autopilot will lock on the current heading.
The course-to-steer is shown on the display.
Disengaging AUTO mode:
Press the AUTO button, a beep will sound and the vessel will
return to manual steering.
Changing the position of the remote unit switch can select
REMOTE AUTO, REMOTE POWER STEER, or MANUAL
modes.
Course Adjustment:
Each press of the < or > buttons will cause a one degree per
segment course change in the applicable direction. The display
will change to indicate the new course-to-steer. By pressing and
holding the buttons pressed will cause the change to be at 10
degrees per second for larger turns.
