Introduction

Congratulations on your wise choice and purchase of the TMQ AP55
Autopilot Display Head. We are sure that you will enjoy the benefits that
it offers.
The AP55 head utilises an existing Autopilot system and provides full
control of the autopilot, indicating in different modes heading, course to
steer and rudder angle.
The minimum AP55 Autopilot system must comprise the following
units: -
Essential Electronics:
• AP55 Display head.
• Autopilot control unit
• Rudder feedback unit.
• Fluxgate compass
• Drive unit, for example
- Hydraulic system with solenoid valves.
- Reversing hydraulic pump system.
- Mechanical motor drive system.
TMQ AP55 Display Head
Complete AP55 Autopilot System
Page 5 Ver1.0 08/12/2005
