TMQ AP55 Display Head Operation And Installation page 31

Linear drives
Mechanical drives
Computer Software
TMQ AP55 Display Head
Single rod linear drives can be
fitted to a wide variety of vessels.
May be attached directly to the
tiller or rudder quadrant.
Mechanical drive units in 12 or 24 volt DC to
suit vessels with existing mechanical steering.
Supplied with standard chain and socket.
TMQ AP1000 Autopilot operating Software.
Computer control program enabling autopilot
control from a standard PC with serial com
ports. (Cable required)
(Note: Connect to 'NMEA' socket on C-Drive)
Page 31 Ver1.0 08/12/2005
