Page 6
Flex Head........................Tooling........................Water System......................Belt Paths........................Technical Specifications....................List of Fault or Alarm Indicators..................Certificate of Declaration and Conformity................
Should the user fail to comply with these, SASE Company Inc or its representatives are free from all liability both directly and indirectly. Read through these operating instructions and make sure that you understand the contents before starting to use the machine.
Page 8
Safety Instructions Check that the cord and extension cord are intact and in good condi- tion. Never use the machine if the cord is damaged, hand it in to an WARNING HIGH VOLTAGE! authorized service workshop for repair. Does not use a rolled up extension cord. Inspection and/or maintenance should be carried out Electrical cords must not exceed 200ft in length.
As with all electronic equipment, the drives are sensitive to excessive vibration, rough treatment and high levels of dust. Much care and atten- tion has been given by SASE to ensure maximal protection is given to the drive. Note the shock absorbing mounting system used to mount the steel cabinet on the machine chassis/frame.
Once both a speed and direction have been nominated, switch on dust extraction or vacuum device. IMPORTANT! It is highly recommended to use a SASE BULL 1250 Industrial Vacuum system for complete dust control. ...
Changing of Diamonds Different applications often require different selections of diamond tooling. There will be many occasions when the grinding discs need to be changed. Following is a guide for this procedure. Preparation Press the Stop button and engage the Emergency Stop button. As an extra precaution, unplug power cord to prevent unintentional starting of the machine while changing disc, which could result in serious injury.
Determining Diamond Selection Diamond Background Diamond abrasives usually consist of 2 components: Diamond powder (also known as diamond crystals or grit). By chang- ing the size of the diamond powder or grit, we can change how coarse or fi ne the scratches will be that are left behind from the grinding process.
5 5 5 5 PDG 8000 Final Assembly SCALE: 1:15 WEIGHT: 519.9kg SHEET 1 OF 1...
Page 17
Final Assembly Item No. Part No. Description Quantity NB.12.255 M16-2.0x40 Socket Head Cap Screw HOL.U11899 15KW Motor HOL.U11970 Plastic Motor Fan Cover (Not Shown) HOL.900016 Motor Fan (Not Shown) NB.70.109 Motor Key PDG.80071.00 Motor O-Ring PDG.80065.00 Ballast Weight NB.10.121 1-8x4 Hex Head Cap Screw NB.11.108 M6-1.0x16 Hex Flanged Head Cap Screw PDG.80066.00...
Item 9 is installed into item 2 and item 7 fastens items 2&3 together PDG 8000 Frame w/o Drum SCALE: 1:10 WEIGHT: 111kg SHEET 1 OF 1...
Page 19
Frame without Drum Item No. Part No. Description Quantity PDG.80055.00 Water Tank PDG.80056.00 Right Hand Half Shell PDG.80057.00 Left Hand Half Shell See Page # 20 Handle Assembly PDG.80200.00 20HP 230V 50-60Hz Drive PDG.80201.00 20HP 380-460V 50-60Hz Drive NB.13.116 M6-1.0x20 Socket Flat Head Cap Screw NB.11.121 M8-1.25x16 Flanged Hex Head Cap Screw NB.11.112...
HANDLE BAR MUST BE "THREADED" THROUGH ITEM 9 AND THEN ITEM 2 CAN BE USED TO TIGHTEN HANDLE POSITION ITEM 8 IS TO BE INSTALLED AROUND STEM LOCK ON VERTICAL FRAME MEMBER TITLE: Handle Assembly SCALE: 1:6 WEIGHT: 18.6kg SHEET 1 OF 1...
Page 21
Handle Assembly Item No. Part No. Description Qty. NB.12.219 M8-1.25x25 Socket Head Cap Screw NB.20.135 M40-1.5 Shaft Nut PDG.20232.00 Handle Bar PDG.20229.00 Stem Lock Actuator PDG.20228.00 Handle Stem Lock PDG.20227.00 Handle Stem Lock Lever PDG.20230.00 Handle Stem Cover PDG.20226.00 Handle Stem Cap PDG.20225.00 Handle Stem NB.12.235...
Page 27
Complete Drum Item No. Part No. Description Quantity See Page # 32 Bottom Drum Assembly III See Page # 34 Top Plate Assembly PDG.80042.00 Stationary Plate PDG.80044.00 Bottom Belt Dust Shroud PDG.80046.00 Drum Mounting Ear PDG.80043.00 Top Belt Dust Shroud NB.13.252 M10-1.5x30 Socket Flat Head Cap Screw PDG.80072.00...
5 5 5 PDG 8000 Bottom Drum Assembly Level II SCALE: 1:8 WEIGHT: 101.4kg SHEET 2 OF 3...
Page 31
Bottom Drum Assembly Level II Item No. Description Quantity PDG.80027.00 Bottom Drum Plate See Page # 50 Main Belt Spindle See Page # 46 Belt Tightener NB.12.108 M6-1.0x12 Socket Head Cap Screw NB.12.111 M6-1.0x16 Socket Head Cap Screw NB.12.213 M8-1.25x16 Socket Head Cap Screw See Page # 48 Main Belt Idler NB.18.140...
DETAIL A SCALE 1 : 4 PDG 8000 Bottom Drum Assembly Level III SCALE: 1:8 WEIGHT: 101.4kg SHEET 1 OF 3...
Page 33
Bottom Drum Assembly Level III Item No. Part No. Description Quantity PDG.80008.00 Idler Reinforcing Link PDG.20208.00 Tensioner Control Bar PDG.20207.00 Main Belt Tensioner Rod NB.20.120 Tensioner Nut NB.20.111 M12-1.75 Jam Nut NB.15.251 M12x60 Socket Head Shoulder Bolt See Page # 54 PTO Assembly See Page # 52 Planetary Assembly...
PDG 8000 Top Plate Assembly SCALE: 1:6 WEIGHT: 48.9kg SHEET 1 OF 1...
Page 35
Top Plate Assembly Item No. Part No. Description Quantity PDG.80028.00 Top Drum Plate See Page # 40 PTO Tensioner Assembly See Page # 44 Top Tensioner Assembly See Page # 42 Top Belt Idler Assembly NB.12.252 M12-1.75x30 Socket Head Cap Screw NB.12.108 M6-1.0x12 Socket Head Cap Screw NB.13.218...
Install O-Ring with dab of grease & prior to inserting bolt PDG 8000 Top Belt Idler Assembly SCALE: 1:2 WEIGHT: 1.1kg SHEET 1 OF 1...
Page 43
Top Belt Idler Assembly Item No. Part No. Description Quantity PDG.80038.00 Top Belt Idler Base PDG.80037.00 Top Belt Idler PDG.20220.00 Bearing 3204-2RS PDG.20215.00 M30 O-Ring PDG.80078.00 M20-2.5x46.8 Socket Head Screw...
Install O-Ring with dab of grease & prior to inserting bolt PDG 8000 Top Tensioner Assembly SCALE: 1:3 WEIGHT: 1.93kg SHEET 1 OF 1...
Page 45
Top Tensioner Assembly Item No. Part No. Description Quantity PDG.20210.00 Top Belt Tension Idler Spacer PDG.80035.00 Top Belt Tension Idler PDG.20220.00 Bearing 3204-2RS NB.13.116 M6-1.0x20 Socket Flat Head Cap Screw PDG.20206.50 Top Belt Tensioner Clamp PDG.20205.50 Top Belt Tensioner Plate PDG.20215.00 M30 O-Ring NB.12.263...
PDG 8000 Main Belt Idler SCALE: 1:3 WEIGHT: 2.27kg SHEET 1 OF 1...
Page 49
Main Belt Idler Item No. Part No. Description Quantity PDG.80011.00 Main Belt Idler Spindle PDG.80010.00 Main Belt Idler PDG.20219.00 Bearing 63008-2RS PDG.80009.00 Idler Bearing Retainer NB.50.143 Hardened Pin M8x26...
Rest snap ring on spindle before pressing on bearings PDG 8000 Main Belt Spindle SCALE: 1:3 WEIGHT: 6.35kg SHEET 1 OF 1...
Page 51
Main Belt Spindle Item No. Part No. Description Quantity PDG.80002.01 Main Drive Sheave Rev 1 PDG.20218.00 Bearing 62208-2RS PDG.80003.00 Outer Main Bearing Spacer PDG.80004.00 Inner Main Bearing Spacer NB.40.130 Internal Retaining Ring M80 PDG.80005.00 Main Bearing Spindle NB.40.110 External Retaining Ring M40 NB.18.142 M6-1.0x16 Tipped Socket Head Set Screw...
Tooling Item No. Part No. Description Quantity See Page # 56 Flex Head NB.30.212 M8 Lock Washer NB.12.219 M8-1.25x25 Socket Head Cap Screw NB.13.118 M6-1.0x12 Socket Flat Head Cap Screw PDG.80076.00 PDG8000 Tooling Plate HOL.904132 Quick Change Adapter NB.13.216 M8-1.25x16 Flat Head Socket Cap Screw...
Control Box Item No. Part No. Description Quantity PDG.20341.00 FAN, 24V DC FOR DRIVE PDG.20342.00 HOLDER, FUSE SPARE PDG.20342.01 FUSE, 250V 10A PDG.20343.00 SUPPLY, POWER LOW VOLT PDG.20343.01 SUPPLY, POWER HIGH VOLT PDG.20344.00 TERMINAL, CONNECTION DR1.5/4 PDG.20345.00 TERMINAL, BLOCK M10/10P PDG.20346.00 TERMINAL, M35/16P PDG.80202.00...
Page 69
Prior to any repair work on the machine and its drives, secure the machine against unintentional powering on. Problem Possible cause Remedy Excessive Imbalance due to worn or Replace all worn or broken broken grinding tools. parts. Vibration Screws worked loose on the grinding disc. ...
Page 70
Prior to any repair work on the machine and its drives, secure the machine against unintentional powering on. Problem Possible cause Remedy Missed phase Motor does not Check the main power supply switch on and switch on again Replace Defective component ...
Page 71
(1) year from original date of purchase. In the event that you should have a claim SASE shall repair, replace or remedy the defective parts resulting from the faulty design, materials or workmanship. Note: This warranty is only valid for equipment either sold by SASE or by an authorized wholesaler or distributor.
Page 72
SASE PRODUCT & WARRANTY REGISTRATION WARRANTY IS VOID IF NOT RETURNED AND REGISTERED WITH SASE WITHIN 30 DAYS OF PURCHASE COMPANY NAME AND TITLE STREET ADDRESS CITY STATE COUNTRY PHONE EMAIL DATE OF PURCHASE SERIAL NUMBER INVOICE NUMBER OF PURCHASE...
