:S =STR1
:JU =CON0
:
WCON :
:DO =CDB
:L DW 0
:L KH 0000
:!=F
:BEB
:L DL 3
:><F
:JC =FAUL
:
READ :
:DO =RDB
:L KH 8081
:T DW 0
:L KH 0003
:T DW 1
:L KB 0
:T DR 4
:
:A F 0.1
:RB =STR1
:S =STR2
:JU =CON0
:
RCON :
:DO =CDB
:L DW 0
:L KH 0000
:!=F
:BEB
:L DL 3
:><F
:JC =FAUL
:L DW 4
:SLW 5
:L =PKEW
:SLW 5
:!=F
:JC =OK
:JU =READ
24
Gateway InterBus-S
Write_Request executed
Delete conf and send order
**** Wait for Write_Confirm.
Open confirmation DB
Retrieve conf_identification
;is 0 then wait again
retrieve Result
is not ZERO
-> FAULT
*** execute READ-REQUEST ****
Open Request DB
Order identification Read_Request
Parametercounter = 3
No. of bytes = 0
CR; Object and VLT remain
VKE"1"
STR1=0 AND STR2=1
-> wait for Read_confirmation
Delete conf and send order
*** wait for READ-Confirmation
Open confirmation DB
Retrieve confirmation identification
is 0 then wait again
Retrieve Result-Code
is not 0
-> FAULT
Retrieve PCA received
only Para-number
Retrieve Para-number sent
Only Para-number
equal then OK
Enter value
if NOT ZERO, then READ again
