- Page 1 BatteryPlus35 FOR MODELS BP35-HA BP35-PM BP35-SR TEAM BMPRO .COM...
- Page 2 Australia, and represent a high-quality product that will provide years of service. DISCLAIMER BMPRO accepts no liability for any loss or damage which may occur from the improper or unsafe use of its products. Warranty is only valid Copyright © 2019...
-
Page 3: Safety Precautions
SAFETY PRECAUTIONS Please read the Safety Precautions before installing or using the BatteryPlus35. Be sure to observe all precautions without fail. Failure to observe these instructions properly may result in personal damage, or personal injury which depending on the circumstances may be serious and cause loss of life. Correct installation is the most critical factor in ensuring the safe use of the BatteryPlus35. -
Page 4: About The Batteryplus35
ABOUT THE BATTERYPLUS35 BMPRO’s BatteryPlus35 is a battery management system designed specially for use in recreational vehicles. The BatteryPlus35 operates from 100 to 240V AC mains power supply, towing vehicle auxiliary and solar panel to provide 35A of current to simultaneously power caravan loads and charge the caravan battery. -
Page 5: Compatible Battery Types
COMPATIBLE BATTERY TYPES The BatteryPlus35 is rated to charge battery banks of up to 600Ah in capacity and of the following battery types: BATTERY BP35-PM BP35-SR BP35-HA* Lead Acid Valve-Regulated (VRLA) Absorbed Glass Mat (AGM) ... -
Page 6: Table Of Contents
CONTENTS SAFETY PRECAUTIONS ABOUT THE BATTERYPLUS35 WHAT’S INCLUDED ........4 OPTIONAL ACCESSORIES ........4 COMPATIBLE BATTERY TYPES ........5 BATTERYPLUS35 ........7 INSTALLATION INSTRUCTIONS ........9 REPLACING BATTERIES ........9 DISCONNECTING A BATTERY FROM THE BATTERYPLUS35 ......10 CONNECTING A BATTERY TO THE BATTERYPLUS35 ......10 CONNECTING MULTIPLE BATTERIES ......10 USING YOUR BATTERYPLUS35 ......11... -
Page 7: Batteryplus35
BATTERYPLUS35 Figure 1: The BatteryPlus35 MAINS CABLE The BatteryPlus35 is pre-cabled with a permanent mains power supply cord for use with 240V or 110V input power. Do not replace a damaged power supply cord. If the power cord is damaged, the BatteryPlus35 must be discarded. - Page 8 Table 3: Load Output Operational Status Indications SYSTEM STATUS INDICATOR Indicates the operational status of the BatteryPlus35. CAN BUS COMMUNICATION CONNECTOR To connect to and power BMPRO accessories (BC300 + CommLink External Shunt or OdysseyLink) or monitors (RVView or Trek). NOT IN USE...
-
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS REPLACING BATTERIES Before using a battery other than that which was installed at the caravan dealership, consult with the battery manufacturer for a detailed description of the installation, uses and maintenance of the battery. Verify that the type and capacity of the battery or batteries used are compatible for use with the BatteryPlus35. -
Page 10: Disconnecting A Battery From The Batteryplus35
DISCONNECTING A BATTERY FROM THE BATTERYPLUS35 To disconnect a battery from the BatteryPlus35: Power off all loads connected to the BatteryPlus35, the easiest way is with the switch connected to the BatteryPlus35 RSW input Turn off and remove all power sources (mains/solar/AUX) to the BatteryPlus35 Disconnect the battery’s negative (black) terminal from the BatteryPlus35 Batt- connection point... -
Page 11: Using Your Batteryplus35
USING YOUR BATTERYPLUS35 INPUT POWER SOURCES The BatteryPlus35 may be powered from auxiliary, mains and solar input sources. When multiple inputs are available to the BatteryPlus35, the BatteryPlus35 uses power as specified in the tables below to provide the current to simultaneously power caravan loads and charge the caravan battery. -
Page 12: Battery Charging And Management
Solar Input on the BP35-PM DO NOT connect solar panels directly to the BP35-PM solar input terminals. Connection of solar panels to the BP35-PM must always be through an external regulator. The external regulator may either be a Maximum Power Point Tracker (MPPT) regulator or Pulse Width Modulator controller. - Page 13 Solar Charging with the BP35-HA and BP35-SR When charging the battery from solar, the BP35-HA and BP35-SR applies a multi- stage charging algorithm. The BatteryPlus35 (HA and SR) will use solar as a charging source is the voltage generated by the solar panel is greater than 17.5V for at least two minutes. Battery Health Preservation The BatteryPlus35 preserves battery health by preventing the battery from excessive discharge.
- Page 14 STORAGE MODE Power to load output terminal 1 and the CAN bus will now be turned off; meaning no communication or power to the accessories connected to the BatteryPlus35 CAN bus. To exit Storage Mode, start battery charging. The BatteryPlus35 will exit Storage Mode when the battery charges to the Recovery voltage.
-
Page 15: Using The Batteryplus35 As A Power Supply
USING THE BATTERYPLUS35 AS A POWER SUPPLY (BATTERY-LESS OPERATION) The BatteryPlus35 will act as a power supply if the following conditions are met: 1. A battery is not connected to the BatteryPlus35, and 2. The BatteryPlus35 is configured to charge Lead Acid batteries, and 3. -
Page 16: Servicing, Maintenance And Storage
BatteryPlus35 yourself; this will void your warranty. If your BatteryPlus35 requires servicing other than what is stated in this Owner’s Manual, please consult your BMPRO dealer. MAINTENANCE Use a dry or moist cotton cloth to lightly remove dust or dirt from the BatteryPlus35. -
Page 17: Faqs And Troubleshooting
(03) 9763 0962. BATTERY I’ve fitted a battery to the BatteryPlus35, but it’s not detected by my BMPRO battery monitor? Check the following: Battery connections are tight and not loose or corroded... -
Page 18: Solar
None of my loads appear to be powered and the screen on my battery monitor has turned off? All loads, including any battery monitor in use with the BatteryPlus35 will power down if the BatteryPlus35 was put into Storage Mode. The BatteryPlus35 will be put into Storage Mode if: The user activated the switch connected to the BatteryPlus35 RSW input. -
Page 19: Appendices
APPENDICES BATTERYPLUS35 OPERATIONAL STATUS INDICATOR The following details the operational status of the BatteryPlus35, as shown by the coloured flash of the LED Status Indicator on the BatteryPlus35. Colour Code Flashing Status AC Charging On, Solid Low Battery Voltage Flashes, 1 Time BP35-PM Solar Charging Flashes, 2 Times Quickly... -
Page 20: Battery Charging Management Algorithm
BATTERY CHARGING MANAGEMENT ALGORITHM The following describes the Battery Charging Management Algorithm used by the BatteryPlus35 when charging the caravan battery from a mains power source and by the BP35-HA and BP35-SR with solar charging. The BatteryPlus35 will operate as described when the caravan loads are connected directly to the BatteryPlus35 and not the caravan battery. - Page 21 Voltage Limit (V) Curent Limit (A) LifePO4 Charge Mode Lead Acid BP35-PM BP35-SR BP35-HA (BP35-HA Only) Soft Start 12.3 12.3 Bulk 14.4 14.6 Absorption 14.4 14.6 Float 13.6 13.6 Table 7: Battery charging management algorithm voltages and currents The BatteryPlus35 intelligently controlled charging algorithm, automatically sets charging parameters so that the caravan battery will maintain the best state of health.
-
Page 22: Specifications
SPECIFICATIONS BP35-PM BP35-SR BP35-HA Input Voltage Range 110-240V AC ± 10%, 50-60Hz Input Surge < 40A (cold start) Output Current 35A (Load + Battery Current) Factory Set Voltage 13.65V (Float Voltage) Output Ripple Voltage <150mV Battery Current Limit max. 20A max. -
Page 23: Warranty Terms And Conditions
5. BMPRO may seek reimbursement of any costs incurred by BMPRO when a product is found to be in proper working order or damaged as a result of one or more of the warranty exclusions mentioned in point 4 of this statement. - Page 24 BMPRO TEAM +61 3 9763 0962 sales@teambmpro.com BMPRO 19 Henderson Rd, Knoxfield VIC 3180 Australia .COM teambmpro.com...
