Cooling:
Air temperature at the inlet on the indoor device:
27°C for dry thermometer bulb (DB), 19°C for wet
thermometer bulb (WB). Outdoor air temperature:
35°C for dry thermometer bulb (DB), 24°C for wet
thermometer bulb (WB).
Heating:
Air temperature at the inlet on the indoor device:
20°C for dry thermometer bulb (DB), 15°C for wet
thermometer bulb (WB). Outdoor air temperature:
7°C for dry thermometer bulb (DB), 6°C for wet
thermometer bulb (WB).
Temperature ranges:
Cooling
Room temperature
Outdoor temperature
Heating
Room temperature
Outdoor temperature
Notes:
1. For health reasons the room temperature should
be no more than 5 – 6°C below the outdoor
temperature in cooling mode.
2. The perfect performance of the system is
achieved within the temperature ranges shown in
the table.
3. If the air conditioning system is operated below
the temperature range shown above, protection
functions may be activated in certain
circumstances which will cause the device to
operate abnormally.
4. If the air conditioner is operated in a relative
humidity level of over 80%, condensation may be
deposited on the top of the system which will
then drip on to the floor. In this case set the
horizontal air flap to its maximum angle
(perpendicular to the floor) and set the FAN to
"HIGH".

4. Intended use

The air conditioner is only designed for cooling,
heating or dehumidifying private homes or
bedrooms.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
10
24.01.2008 8:17 Uhr
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
5. Description of parts (Fig. 1)
IA = Indoor device A
IB = Indoor device B
1 Front panel
2 Air filter
3 Vertical air slit
4 Display panel
5 Emergency switch
6 Condensation hose
16°C ~ 31°C
7 Remote control
> +18°C
8 Mains cable
9 Air outlet
16°C ~ 31°C
Important. Both indoor devices must be correctly
> +7°C
connected to the outdoor device. There is a risk of
damage to the device if installed incorrectly. Damage
caused by incorrect installation is not covered by the
warranty.
6. Indoor device display (Fig. 2)
1 LED 7-segment display
2 Temperature display symbol
3 Heating mode symbol
4 Dehumidifying mode symbol
5 Timer mode symbol
6 Sleep symbol (economy mode)
7 Speed display for indoor fan
8 Automatic mode symbol
9 Cooling mode symbol
10 Air flow up/down symbol

7. Setting up the remote control

Insert batteries
1. Open the battery compartment cover.
2. Insert two new batteries. Be sure to observe the
correct polarity (+/-) of the batteries.
3. Close the battery compartment cover.
Notes
The radio signal has a range of approx. 8 m.
Use two alkali batteries, type R03 AAA (1.5 V).
Always replace both batteries at once when you
can no longer see the LCD display.
