Sub-Zero BI-36U Design Manual page 36

Dual Installations
Dual Installation Kit with Dual Wide Grille.
This kit will replace the existing grilles that ship with the
units and span the entire width of both units. The kit
1
includes a / " (6) center trim strip (required for proper
4
installation of the dual wide grille), heater, dual kickplate
and mounting hardware. Dual wide grilles are available for
all built-in models and design applications. The overlay
dual installation kit with grille will accept overlay and dual
flush inset panels. For dual wide grille panel dimensions,
refer to the panel specifications below for your design
application. Grille panel dimensions listed are for a
standard 84" (2134) overall height of the unit.
Dual Wide Grille—Overlay Panels
Two 30" Models
(762)
DUAL WIDE GRILLE
Overlay Panel
Spacer Panel
Backer Panel
Dual Wide Grille—Flush Inset Panels
Two 30" Models
(762)
DUAL WIDE GRILLE
Flush Inset Panel
Spacer Panel
Backer Panel
W H
1 1
60 / " 9 / "
(1530) (235)
4 4
3 5
59 / " 8 / "
(1558) (211)
8 16
15
60" 8 / "
(1524) (227)
16
W H
1 1
61 / " 9 / "
(1556) (235)
4 4
3 5
59 / " 8 / "
(1558) (211)
8 16
15
60" 8 / "
(1524) (227)
16
Dual Installation Kit.
This kit is available for those
who choose to utilize the individual grilles that ship with
each unit. The kit includes a
the reveal between the units and grilles), heater and
mounting hardware. This dual installation kit is not
required if a custom filler strip is used. The filler strip
should be a minimum of 2" (51) wide. Refer to full-scale
template on page 41 for more information.
Two 36" Models
(914)
DUAL WIDE GRILLE
Overlay Panel
Spacer Panel
Backer Panel
Two 36" Models
(914)
DUAL WIDE GRILLE
Flush Inset Panel
Spacer Panel
Backer Panel
36
1
/ " (6) filler strip (which fills
4
W H
1 1
72 / " 9 / "
(1835) (235)
4 4
3 5
71 / " 8 / "
(1813) (211)
8 16
15
72" 8 / "
(1829) (227)
16
W H
1 1
73 / " 9 / "
(1861) (235)
4 4
3 5
71 / " 8 / "
(1813) (211)
8 16
15
72" 8 / "
(1829) (227)
16
