Flush Inset Panels - Sub-Zero BI-36U Design Manual

Flush Inset Application
This brand new design option allows for a flush door and
grille. Classic, platinum and carbon stainless steel panels
are available as sales accessories. Shown with tubular
handle option to mirror Wolf L Series ovens.
Flush Inset Application.
the following points when planning for a flush inset
application:
• The flush inset depth is 2
standard opening.
• The flush inset width is 2
standard opening.
1
• The flush inset height is
standard opening.
• Panel widths increase to achieve the flush inset look.
1
• You must allow a / " (13) reveal around the perimeter
2
of the unit and grille to allow for proper door swing
and airflow.
IMPORTANT NOTE: Do not confuse the flush inset applica-
tion as being a separate model. This is an overlay unit in a
flush installation. The same model is used in an overlay or
flush inset application.
Rough opening dimensions for the new flush inset appli-
3
cation assume the use of a
illustrations below show the difference between standard
and flush inset installations.
STANDARD INSTALLATION
24"
(610)
OPENING
DEPTH
TOP VIEW
Standard installation.
22
It is necessary to consider
3
/ " (56) deeper than the
16
1
/ " (64) wider than the
2
/ " (6) higher than the
4
/ " (19) decorative panel. The
4
FLUSH INSET INSTALLATION
3 / "
WITH 4 (19) PANEL
3
24" 26 / "
(610) 16
OPENING (665)
DEPTH FLUSH
INSET
DEPTH
TOP VIEW
3 1
2 / " 1 / "
16 4
(56) (32)
Flush inset installation.
