O
VERVIEW
The SmartStrike map card contains Humminbird LakeMaster map data for freshwater lakes in your region. Use the SmartStrike map
card to set specific search parameters, such as fish species and time of day, to locate fish. The search results are highlighted in
pink on the Chart Views, so you can quickly target spots to investigate.

SmartStrike

The following features are exclusive to the SmartStrike map card and can be applied to the Chart View and Chart Combo Views:
Species Search
Preset Searches
Advanced Search

Humminbird LakeMaster

The following Humminbird LakeMaster features are included on the SmartStrike map card and can be applied to the Chart View and
Chart Combo Views. To adjust the menu settings, press the MENU key twice. Select the HB Chart tab. For more information, see your
control head operations manual.
Depth Highlight
Depth Highlight Range
Water Level Offset
Shallow Water Highlight

i-Pilot Link

The following features are available if you have i-Pilot Link connected to your HELIX control head and a Minn Kota trolling motor
installed on your boat:
Follow the Contour
Contour Offset
For more information, see the i-Pilot Link Installation and Operations Guide.
Species Search allows you to search the lake for a specific fish species. Select the species
name and the time of year, time of day, weather conditions, wind conditions, and water
conditions you want to target.
Preset Searches allow you to choose a preselected search based on water depth and
underwater structure.
Advanced Search allows you to refine your preset search or create your own search using
criteria such as lake region, depth/slope, sun and direction, proximity, and structure.
Highlight a depth setting in the Chart Views. The depth you set will be highlighted in green.
Use Depth Highlight with Depth Highlight Range (see below).
Adjust the range on each side of the highlighted depth, when a Depth Highlight is active in
the Chart Views.
Change the level of the water being read from the control head. The displayed numbers on
the Contour Lines in the Chart Views will adjust from the Water Level Offset setting, and the
water level offset will be highlighted in dark brown.
Select a minimum shallow depth setting so that the depth is highlighted in red in the Chart
Views.
Navigate a contour on a Humminbird LakeMaster chart. Use Follow the Contour with
Contour Offset (see below).
Set a distance to maintain away from the selected contour line while following a contour.
