Relay Control and Indication
The two test buttons are used to test the built-in relay function. The test
buttons are intended for use during installation to control functionality of con-
nected devices. The LEDs will indicate if the relay is activated (green) or not
activated (off) during use of the test buttons. They will also illuminate when
the relays are controlled by the project in the LiMa.
Be aware that you can activate multiple relays at the same time and
damage connected equipment if not carefull.
uSD-Card
The uSD-Card stores the LiMa project setup created in the Project
Designer software, including general settings and Graphical User
Interface. The card should not be removed during normal operation.
To remove the SD Card from the unit, push it GENTL Y into the holder about
1mm (by using your finger tip). Release again, and it will slide out.
REMEMBER to remove power from unit (power down) before re-
!
moving uSD card!
Power and Error Indication
control
The "on" LED will show the current status of the unit.
1
2
rx
Green
Neets Control - LiMa is on and running normally
tx
Blue
Neets Control - LiMa is starting
Config
Flashing red
The Neets Control - LiMa is in error mode, see section
"Error indication" on page 15 for details
Back
1
2
1
Number:
1
2
3
4
Page 8 of 12
Config
in / out
relay
1
2
1 2
in
out
on
310-0304-002-003 (Artwork Bottom plate) REV1
Description
2 x potential-free relays
2 x Bi-directional RS-232 or IR transmitter
1 x RJ-45 Network (LAN) connector with PoE input
2 x digital I/O
control
Config
control
in / out
relay
1
2
1 2
1
rx
in
tx
out
on
310-0304-002-004 (Artwork Top plate) REV2
2
in / out
relay
1
2
1
1 2
rx
in
tx
out
on
2
310-0304-002-004 (Art
Neets Control - LiMa
on
designed in Denmark
PoE IN
3
4
2
