Specifications

RS-232 (Tx+Rx) or IR (controls up to 2 IR devices on each port)
LAN device control
I/O
Low voltage relay
PoE input
USB port for programming
PIR sensor input
Light on/off
Room darkening
Screen up/down
Volume control
Device feedback
Specifications
Neets Control - LiMa
RS-232 / IR port
Ports
Baud rate
Data bits
Parity
Stop bits
IR frequency
Connector
Input / Output
Ports
Input trigger low
Input trigger high
Output type
Isolated output
Max voltage load
Max current
Connector
Relay Output
Voltage max
Current max
Connector
Network (LAN)
Speed
Duplex modes
DHCP
Default IP
Default gateway
Default subnet mask
2 x bidirectional
1200 - 115200 bit/sec
7, 8
Even, Odd, None
1, 2
400 Hz to 500 Hz
3 pin screw block
2 x I/0
< 1VDC
< 4VDC
Open drain
No
24 VDC
0,5 A
3 pin screw block
30 VDC
0,5 A
2 pin screw block
10 / 100 Mbit
Half or Full
Default off
192.168.254.252
192.168.1.1
255.255.255.0
PoE input
Compliance
802.3af PD mode
PD Class
General
Width
Height
Depth
Width
Height
Depth
Weight
Shipping weight
Shipping dimension
(W/D/H)
Storage temperature
Storage moisture
Operation temperature 0 ˚C to 30 ˚C
Operation moisture
Product number
310-0304
Approvals
IEC/EN
IEC/EN
FCC
CE
2
10
2
2
1
1
Yes
Yes
Yes
Yes
Yes
Yes
802.3af / 802.3at
A + B
0 (802.3af) / 4 (802.3at)
220 mm
35 mm
70 mm
8,66 inches
1,38 inches
1,46 inches
0,5 kg
1,0 kg
280 mm / 190mm /
55 mm
-20 ˚C to 50 ˚C
Non-condensing
Non-condensing
LiMa
61000-6-1
61000-6-2
Part 15, Class A
