- Page 1 DOL 26 SCR/PNP/NPN Capacitive Proximity Sensors TECHNICAL USER’S GUIDE For other language variants of this document we refer to www.dol-sensors.com or your local dealer. www. dol-sensors a/s Hedelund 4, Glyngøre 7870 Roslev Denmark Tel. +45 72 17 58 88 Fax +45 72 17 59 59 www.dol-sensors.com...
- Page 2 EN – TECHNICAL USER GUIDE PRODUCT FUNCTIONALITY DOL 26 is a capacitive sensor for detecting loose and solid DOL 26SCR, incl. load, can be supplied with 20-280 materials. VAC/VDC 47-63 Hz SCR output versions are available in 2-wire versions. Maximum current (I ) of 500 mA for all SCR, PNP and NPN.
-
Page 3: Led Indication
EN – TECHNICAL USER GUIDE INSTALLATION GUIDE DOL 26SCR: Connect the sensor in series with the load. The polarity is unimportant. The sensor is protected against overload and short circuit. If the output current exceeds the nominal output current, the output function is switched off. - Page 4 C-UL C-UL * Option – can be changed / introduced upon request. See the current functions in the product label. For more info: www.dol-sensors.com Dol Sensors Hedelund 4, Glyngøre 7870 Roslev Denmark Tlf. +45 72 17 55 55 Fax +45 72 17 59 59...
