INSTRUCTION MANUAL / INSTALLATION MANUAL
60cm Ceramic
Cooktop
MODEL: KACRMICCTPA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KACRMICCTPA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kogan KACRMICCTPA

Summary of Contents for Kogan KACRMICCTPA

  • Page 1 INSTRUCTION MANUAL / INSTALLATION MANUAL 60cm Ceramic Cooktop MODEL: KACRMICCTPA...
  • Page 2 THIS PAGE IS INTENTIONALLY LEFT BLANK...

  • Page 3: Table Of Contents

    CONTENTS General Safety Warnings Product Overview Before using your New Ceramic Hob Choosing the right Cookware Using your Ceramic Hob Locking the Controls Using the Timer Cooking Guidelines Heat Settings Care and Cleaning Hints and Tips Technical Specification Installation Warranty...
  • Page 4 THIS PAGE IS INTENTIONALLY LEFT BLANK...

  • Page 5: General Safety Warnings

    General Safety Warnings ELECTRICAL SHOCK HAZARD IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE Your safety is important to us. Read this manual thoroughly before first use, even if you are familiar with this type of product. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to.
  • Page 6 Electrical Shock Hazard • Do not cook on a broken or cracked cooktop. If the cooktop surface should break or crack, switch the appliance off immediately at the mains power supply (wall switch) and contact a qualified technician. • Switch the cooktop off at the wall before cleaning or maintenance. •...
  • Page 7 • Do not place or drop heavy objects on your cooktop. • Do not stand on your cooktop. • Do not use pans with jagged edges or drag pans across the Ceramic glass surface as this can scratch the glass. •...

  • Page 8: Product Overview

    Product Overview TOP VIEW 1. max. 1800 W zone 2. max. 1200 W zone 3. max. 1800 W zone 4. max. 1200 W zone 5. Glass plate 6. Control panel CONTROL PANEL 1. Power regulating key 2. Timer regulating key 3.

  • Page 9: Before Using Your New Ceramic Hob

    Before using your New Ceramic Hob Read this guide, taking special note of the ‘Safety Warnings’ section. Remove any protective film that may still be on your ceramic hob. USING THE TOUCH CONTROLS • The controls respond to touch, so you don’t need to apply any pressure. •...

  • Page 10: Using Your Ceramic Hob

    Using your Ceramic Hob TO START COOKING After powering on, the buzzer beeps once, all the indicators light up for 1 second then go out, indicating that the ceramic hob has entered the state of standby mode. 1. Touch the ON/OFF control. all the indicators show “-” 2.

  • Page 11: Locking The Controls

    2. Beware of hot surfaces H will show which cooking zone is hot to touch. It will disappear when the surface has cooled down to a safe temperature. It can also be used as an energy saving function if you want to heat further pans, use the hotplate that is still hot.

  • Page 12: Using The Timer

    Using the Timer You can use the timer in two different ways: • You can use it as a minute minder. In this case, the timer will not turn any cooking zone off when the set time is up. • You can set it to turn one or more cooking zones off after the set time is up. •...
  • Page 13 SETTING THE TIMER TO TURN ONE OR MORE COOKING ZONES OFF If the timer is set on one zone: 1. Touch the”-“ or ”+” of the corresponding cooking zone you want to set the timer for. 2. Set the time by touching the “-“ or “+” control of the timer Hint: Touch the “-“...

  • Page 14: Cooking Guidelines

    IF THE TIMER IS SET ON MORE THAN ONE ZONE 1. When you set the time for several cooking zones simultaneously, decimal dots of the relevant cooking zones are on. The minute display shows the shortest time frame you have selected. The dot of the corresponding zone flashes.

  • Page 15: Heat Settings

    FOR STIR-FRYING 1. Choose a ceramic compatible flat-based wok or a large frying pan. 2. Have all the ingredients and equipment ready. Stir-frying should be quick. If cooking large quantities, cook the food in several smaller batches. 3. Preheat the pan briefly and add two tablespoons of oil. 4.

  • Page 16: Care And Cleaning

    Care and Cleaning WHAT? HOW? IMPORTANT! 1. Switch the power to the cooktop Everydaysoilingonglass • Whenthepowertothecooktop off. (fingerprints,marks,stainsleftby isswitchedoff,therewillbeno foodornon-sugaryspilloversonthe ‘hotsurface’indicationbutthe 2. Apply a cooktop cleaner while glass) cookingzonemaystillbehot! the glass is still warm (but not Takeextremecare. hot!) • Heavy-dutyscourers,somenylon 3.

  • Page 17: Hints And Tips

    Hints and Tips PROBLEM POSSIBLE CAUSES WHAT TO DO WHAT TO DO ThecooktopcannotBeturnedon. Nopower. Makesurethecooktopisconnected tothepowersupplyandthatitis switchedon.Checkwhetherthere isapoweroutageinyourhomeor area.Ifyou’vecheckedeverything andtheproblempersists,calla qualifiedtechnician. Thetouchcontrolsare Thecontrolsarelocked. Unlockthecontrols.Seesection unresponsive. ‘Usingyourceramiccooktop’for instructions. Thetouchcontrolsaredifficultto Theremaybeaslightfilmofwater Makesurethetouchcontrolareais operate. overthecontrolsoryoumaybe dryandusetheballofyourfinger usingthetipofyourfingerwhen whentouchingthecontrols. touchingthecontrols. Theglassisbeingscratched. Rough-edgedcookware.Unsuitable, Usecookwarewithflatandsmooth bases.See ‘Choosing the right abrasivescourerorcleaning productsbeingused.

  • Page 18: Installation

    Installation SELECTION OF INSTALLATION EQUIPMENT Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 50mm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant work surface material to avoid larger deformation caused by the heat radiation from the hotplate.
  • Page 19 LOCATING THE FIXING BRACKETS The unit should be placed on a stable, smooth surface (use the packaging). Do not apply force onto the controls protruding from the hob. Fix the hob on the work surface by screw four brackets on the bottom of hob (see picture) after installation. Adjust the bracket position to suit for different work surface’s thickness.
  • Page 20 1. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents. 2. If the appliance is being connected directly to the mains supply, an omnipolar circuit breaker must be installed with a minimum gap of 3mm between the contacts.

  • Page 21: Warranty

    You are also entitled to have the Appliance repaired 3. During the Warranty Period Kogan Australia or its ASR will, at no or replaced if the Appliance fails to be of acceptable quality and extra charge if your Appliance is readily accessible for service, the failure does not amount to a major failure.
