Summary of Contents for Danterm ACT 7
- Page 1 ACT 7 Quick start guide...
-
Page 2: Health And Safety
ACT 7 QUICK START GUIDE... -
Page 3: Table Of Contents
Air flow Troubleshooting The air outlet at the top of the ACT 7 room unit is fitted with grilles that allow the angle of air outlet to be adjusted. In conjunction with the fan speed control switch, the air velocity and direction can be carefully set up to obtain maximum coverage of the area being cooled without causing draughts. -
Page 4: Siting
(five screws). The switch is located at the back of length of the room. If there is more than one ACT 7 in the the electric box in the position shown below. Change the... -
Page 5: Condensate
6.7 litres/1.47 gallons 8.1 litres/1.78 gallons Room unit fluid level 9.5 litres/2.08 gallons The fluid system in the ACT 7 room unit should be at the 10.9 litres/2.39 gallons correct level when delivered. Look through the inspection 12.3 litres/2.70 gallons window and check that the level is between the MAX and MIN on the tank in the back of the room unit. -
Page 6: Controls
There is a six minute delay timer when switching to ‘A/C’ for ducted operation). mode from ‘stand by’ or ‘fan only’ modes. Cooling will start after this delay period. ACT 7 QUICK START GUIDE... -
Page 7: Setting The Desired Temperature
‘Settings menu’. ‘back’ ‘up’ ‘down’ ‘enter’ With the ‘Temperature’ option highlighted press the ‘enter’ key. Use the ‘up’ and ‘down’ keys to change the highlighted value. Pressing enter stores the temperature setting. ACT 7 QUICK START GUIDE... -
Page 8: Fault Symbols
Resetting the alarms Reset Alarms HP Fault LP Fault In the ‘Settings menu’ scroll down to ‘Reset alarm’ and push ‘enter’. Then using the up and down keys highlight the alarm to be reset and push ‘enter’. ACT 7 QUICK START GUIDE... - Page 9 This alarm resets itself and no action is required on the part of the user. When the condensate tank in the ACT 7 is full, a blue bucket flashes on the console. While this is flashing the ACT 7 continues to work for a further 30 seconds.
-
Page 10: Changing The Offset
An offset is used to calibrate the temperature Advanced shown on the main screen. In the ‘Settings menu’ scroll down to ‘Advanced settings’ and push ‘enter’. Highlight ‘Offset’ and push ‘enter’. Use the ‘up and ‘down arrows to change the +/- symbol. ACT 7 QUICK START GUIDE... - Page 11 Press ‘enter’ to move onto the next digit. When ‘enter’ is pressed on the final digit, the value is stored. ACT 7 QUICK START GUIDE...
-
Page 12: Setting The Language
Enable Pin Language In the ‘Advanced menu’ scroll down to ‘Language’ and push ‘enter.’ Language Menu Use the ‘up’ and ‘down’ arrows to select the desired English language. Francais Deutsch Push ‘enter’ to save the changes. ACT 7 QUICK START GUIDE... -
Page 13: Turning Off
Remove the panel by pushing the panel up using recesses at the bottom. Remove the filter, vacuum excess dirt, and wash it with soapy water. Leave the filter to dry before refitting it and operating the ACT 7. Push cover up Recesses... -
Page 14: Troubleshooting
Reset alarm as described in resetting alarms section pressure trip. on page 8. No water or kinked hoses. Top up the ACT 7 room unit header tank with water/ glycol mixture. Insufficient water. External heat exchanger unit mounted in very high ambient... - Page 15 ACT 7 QUICK START GUIDE...
- Page 16 Dantherm Air Handling A/S, Marienlystvej 65, DK-7800 Skive, Denmark Tel. +45 96 14 37 00, Fax +45 96 14 38 20, info@dantherm.com...
