Sperian 4000 Series Manual

Air-purifying respirator full facepiece

Hide thumbs

DO NOT USE this respirator until you completely read and understand this instruction manual. You are

required to inspect your respirator prior to putting it into field service. Please refer to the inspection

procedures in this manual.

I. INTRODUCTION

This manual provides instruction in the use and mainte-

nance of the SPERIAN Series 4000 Full Facepiece Air-

Purifying Respirator. You must read and understand

this manual and be trained in the proper use of this

respirator before wearing it in a contaminated at-

mosphere.

The following table lists the current models available.

Model

Description

410010

Small Facepiece, Blue, 4-Strap

410015

Small Facepiece, Blue, 5-Strap

410071

Small Facepiece, Blue, 4-Strap with Nose Cup

410075

Small Facepiece, Blue, 5-Strap with Nose Cup

410079

Small Facepiece, Black, 5-Strap with Nose Cup

410090

Small Facepiece, Black, 5-Strap

420010

Standard Facepiece, Blue, 4-Strap

420015

Standard Facepiece, Blue, 5-Strap

420071

Standard Facepiece, Blue, 4-Strap with Nose Cup

420075

Standard Facepiece, Blue, 5-Strap with Nose Cup

420079

Standard Facepiece, Black, 5-Strap with Nose Cup

420090

Standard Facepiece, Black, 5-Strap

II. SAFETY PRECAUTIONS

The Warnings, Cautions, and Notes contained in this

manual have the following significance:

WARNING

Maintenance or operating procedures

and techniques that will result in per-

sonal injury or death if not carefully fol-

lowed.

CAUTION

Maintenance or operating procedures and

techniques that will result in damage to

equipment if not carefully followed.

P/N 420094 REV C 03/09

AIR-PURIFYING RESPIRATOR

Series 4000

FULL FACEPIECE

WARNING

AN ISO 9001

REGISTERED

COMPANY

Maintenance or operating procedures and tech-

niques or information considered important enough

to emphasize.

III. DESCRIPTION

This SPERIAN air purifying respirator consists of a

full facepiece made of pliable silicone rubber with two

threaded connectors for attaching particulate filters, gas

and vapor cartridges, and cartridge/filter combinations

as required for specific contaminant protection.

WARNING

• The employer is responsible for establishing that this

respirator is suitable for the user's applications.

• This facepiece must be worn and used as specified in

SPERIAN's instructions.

• Your SPERIAN respirator has been constructed of

materials selected for their performance, safety,

and durability. However, all materials have exposure

limitations to extremes of heat and cold or to the many

chemicals in use today, and could be degraded by

exposure beyond their limitations, creating conditions

in which this SPERIAN equipment would be dangerous

to use.

• Before entering an environment while wearing SPERIAN

equipment, you must conduct safe, scientific tests

to determine if the environment could render the

equipment unsafe. Results of this testing should be

well documented. Seek the help of a certified safety

professional or industrial hygienist. DO NOT USE this

equipment if the user would be endangered in any way

through environmentally induced degradation of the

materials

Sperian Respiratory Protection USA, LLC

3001 South Susan St., Santa Ana, CA 92704

Toll-Free 888.APR.SCBA or 714.545.0410

Fax 714.850.0299

www.sperianprotection.com

NOTE

Table of Contents

Need help?

Do you have a question about the 4000 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Sperian 4000 Series

Page 1 NOTE This manual provides instruction in the use and mainte- Maintenance or operating procedures and tech- nance of the SPERIAN Series 4000 Full Facepiece Air- niques or information considered important enough Purifying Respirator. You must read and understand to emphasize.
Page 2 WARNING in the apparatus. SPERIAN cannot be responsible for • Do not use this respirator at temperatures below -30°F damage to property, personal injury, or death in which (-1°C) or above 130°F (71°C). Do not wear this respirator environmental exposure is a contributing factor.
Page 3 IV. PARTS LIST ACCESSORIES ITEM QTY. (Ea.) DESCRIPTION DESCRIPTION 941723 Headstrap, 4-Strap, Blue 980003 Spectacles Kit 968424 Headstrap, 5-Strap, 980017 Nose Cup Kit Black 140095 Lens Cover 961094 Headstrap, 5-Strap, Blue 951015 Anti-fog Solution (1 oz.) 420002 Standard Skirt, 4-Strap, 951016 Anti-fog Solution (16 oz.) Blue 430000 Welding Shield, Standard Weld...
Page 4 Fully loosen MUST NOT be used. This list is far the lower straps. from complete. Contact SPERIAN Place the neck strap around the back of your for information on other materials. neck.
Page 5 MUST follow the instructions of the manu- F. Filter Replacement facturer who supplies the disinfecting or de- SPERIAN recommends that the filters be changed at contamination equipment or chemicals. least daily, and more often if necessary. The filters must be replaced whenever they become contaminated with dust or water;...
Page 6 All products returned to SPERIAN’s factory, distribu- washing will remove the lens anti-fog coating. Recoat tors, or repair centers must be decontaminated prior with SPERIAN Anti-Fog Solution, P/N 951015 (1 oz.), to shipment. or 951016 (16 oz.). F. Overhaul Frequency 8.
Page 7 Insert a new valve and pull the valve stem until it snaps into place. Replace teh valve grill cover. Perform a facepiece fit check as described in section V, paragraph C. ACCESSORIES Each modification kit and acessory purchased from SPERIAN has installation instructions. Use these instructions for removing and replacing any accessory. www.sperianprotection.com...
