- Page 1 2 / 3-12 / 63-68 CUTTER 45 CT 2 / 13-22 / 63-68 2 / 23-32 / 63-68 2 / 33-42 / 63-68 2 / 43-52 / 63-68 2 / 53-62 / 63-68 www.gys.fr 73502_V3_09/10/2019...
- Page 2 CUTTER 45 CT FIG-1 Matière : Épaisseur : mm FIG-2...
-
Page 3: Safety Instructions
CUTTER 45 CT SAFETY INSTRUCTIONS GENERAL INSTRUCTIONS Read and understand the following safety instructions before use. Any modification or updates that are not specified in the instruction’s manual should not be underta- ken. The manufacturer is not liable for any injury or damage due to a non-compliance with the instructions featured in this manual. -
Page 4: Electrical Safety
CUTTER 45 CT FIRE AND EXPLOSION RISKS Protect the entire working area and ensure that flammable items are stored at a distance of at least 11 meters. Fire extinguishing equipment must be kept in close proximity when cutting materials. Be careful of weld spatter and sparks, even through cracks. If not careful then this could potentially lead to a fire or an explosion. -
Page 5: Equipment Installation
CUTTER 45 CT RECOMMENDATIONS FOR WELDING AREA ASSESSMENT AND WELDING Overview The user is responsible for the installation and use of the arc cutting equipment according to the manufacturer’s instructions. If electromagnetic disturbances are detected, the user is responsible for resolving the situation with the manufacturer’s technical assistance. In certain cases, this corrective action may be as simple as earthing the cutting circuit. -
Page 6: Maintenance Recommendations
CUTTER 45 CT The manufacturer does not accept any liability in relation to damages caused to objects or harm caused to persons as the result of incorrect and/or dangerous use of the machine. MAINTENANCE / RECOMMENDATIONS Ensure the machine is unplugged from the mains, and then wait 2 minutes before carrying out maintenance work. Inside, voltages and currents are high and dangerous. -
Page 7: Power Supply
CUTTER 45 CT INTERFACE (MMI) (FIG-2) Thermal protection indicator Full sheet cutting indicator with the pilot-arc restart Indicator «Stop caused by intervention on the torch» Current setting potentiometer. Malfunction (machine is not functioning normally) indicator Bar-graph Pressure indicator Full sheet cutting indicator Indicator «insufficient pressure»... - Page 8 CUTTER 45 CT TORCH SETUP (MT-70) Refer to the charts on the side of the machine to choose the appropriate consumable. Torch set-up - Plug the torch into the appropriate connector - No machine settings adjustment required Manual cutting 20-50 A...
-
Page 9: Air Pressure Adjustment
CUTTER 45 CT AIR PRESSURE ADJUSTMENT In order to improve cutting performance, make sure air pressure is set to an appropriate level. It is recommended to check / adjust the pressure in case: - of change of connection point or of pneumatic installation... - Page 10 CUTTER 45 CT MANUAL CUT FROM THE EDGE OF THE WORKPIECE: The earth clamp attached to the metal piece, hold the torch pad in perpendicular position (90°) to the end of the workpiece. Pull the trigger of the torch to prime the arc until the torch has completely pass through the part.
-
Page 11: Troubleshooting
CUTTER 45 CT PROTECTIONS Intervention on the torch The operator will have to manipulate and open the torch and its accessories (change of consumables, disconnection of the torch). If the Plasma cutter is switched on during intervention, the screen will display «stop caused by intervention on the torch» (FIG 2 - 2) meaning that the machine has detected an intervention and that it can be carried out safely. -
Page 12: Warranty
CUTTER 45 CT Check that the earth clamp is connec- Arc stops after 3 seconds of cutting No current detection in the earth clamp ted to the cutting part on a clean area (no rust, paint or grease). Check that the power cord of the pro- duct is plugged into the outlet and that the power switch is in the on position. - Page 13 CUTTER 45 CT PIÈCES DE RECHANGE / SPARE PARTS / ERSATZTEILE / PIEZAS DE RECAMBIO / ЗАПЧАСТИ / PEZZI DI RICAMBIO / RESERVE ONDERDELEN Poignée / Handle / Handgriff / Mango / Handvat / Ручка 56048 Ventilateur / Fan / Lüfter / Ventilador / Ventilator / Вентилятор...
- Page 14 CUTTER 45 CT SCHÉMA ÉLECTRIQUE / ELECTRICAL DIAGRAM / SCHALTPLAN / ESQUEMA ELÉCTRICO / ELEKTRISCH SCHEMA / ЭЛЕКТРИЧЕСКАЯ СХЕМА...
- Page 15 CUTTER 45 CT SPÉCIFICATIONS TECHNIQUES / TECHNICAL SPECIFICATIONS / TECHNISCHE DATEN / TECHNISCHE GEGEVENS / ТЕХНИЧЕСКИЕ СПЕЦИФИКАЦИИ PLASMA CUTTER CUTTER 45 CT Primaire / Primary / Primär / Primario / Первичка / Primario / Primaire Tension d’alimentation / Power supply voltage / Stromversorgung / Tensione di alimentazione / Напряжение питания / Tensión...
- Page 16 CUTTER 45 CT ICÔNES / SYMBOLS / SYMBOLE / ICONOS / ZEICHENERKLÄRUNG / PICTOGRAMMEN / ИКОНКИ / ICONE - Attention ! Lire le manuel d’instruction avant utilisation. - Внимание! Прочтите инструкцию перед использованием. - Caution ! Read the user manual.
- Page 17 CUTTER 45 CT - Ce matériel fait l’objet d’une collecte sélective selon la directive européenne 2012/19/UE. Ne pas jeter dans une poubelle domestique ! - This hardware is subject to waste collection according to the European directives 2002/96/UE. Do not throw out in a domestic bin ! - Das Gerät ist geeignet für die Mülltrennung gemäß...
- Page 18 GYS SAS 1, rue de la Croix des Landes CS 54159 53941 SAINT-BERTHEVIN Cedex FRANCE...
