Center Of Gravity; Weights And Dimensions - Johnson Controls R-410A Installation Manual

349218-JIM-F-0512
Before lifting, make sure the unit weight is distributed
equally on the rigging cables so it will lift evenly.
Units may be moved or lifted with a forklift, from the side only,
providing an accessory skid is used.
LENGTH OF FORKS MUST BE A MINIMUM OF 90 INCHES.
All panels must be secured in place when the unit is
lifted.
The condenser coils should be protected from rigging
cable damage with plywood or other suitable material.
A
D
Figure 2: Unit 4 Point Load Weight
Table 2: Weights and Dimensions
Weight (lbs.)
Size
(Tons) Shipping Operating
J15ZJ
2614 2609
(15)
J18ZJ
2670 2665
(17.5)
J20ZJ
2702 2697
(20)
J25ZJ
2788 2783
(25)
8
B
C

Center of Gravity

4 Point Load Location (lbs.)
X Y A
85.25 44 467
85.25 44 477
85.05 44 485
85.25 44 498
A
Figure 3: Unit 6 Point Load Weight
LEFT
Figure 4: Center of Gravity
B C D A
781 852 510 287
797 870 520 293
805 878 529 298
833 908 544 306
C
B
F
Y
X
FRONT
6 Point Load Location (lbs.)
B C D E
392 568 620 428
401 580 633 437
406 585 638 443
419 606 661 457
Johnson Controls Unitary Products
D
E
F
313
320
326
334
