Johnson Controls R-410A Installation Manual page 6

349218-JIM-F-0512
Slide In/ Plug In
Internal Economizer
(Optional)
2" Disposable Filters
(4" Filters Optional)
Copper Tube/
Thermal
Aluminum Fin
Expansion
Evaporator
Valve
Coils
Outdoor Fan #2
Outdoor Fan #1
Outdoor Fan #4
Outdoor Fan #3
Figure 1: J15 thru 25 ZJ Component Location
6
1" NPT
Condensate Drain
Filter Drier
(Solid Core)
Compressor #4
Compressor #3
High Efficiency Scroll Compressors
Electric Heater Location
(Optional Electric/Electric Units)
Location of VFD (Optional)
Location of VFD Bypass (Optional)
Belt Drive
Blower Motor
14 Gauge
Base Rails
with Lifting Holes
Compressor #1
Compressor #2
Unit Control Board
110 Volt Convenience
Outlet ("Powered" or
"Non-Powered" Optional)
Disconnect Location
(Optional Disconnect Switch)
Bottom Power and
Control Wiring Entry
Power Ventor Motor
Copper Tube/Aluminum Fin
Condenser Coils
