Configuration Instructions
CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . . . 1
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-26
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Fan Coil Controller Hardware. . . . . . . . . . . . . . . . . . . . . 2
Field-Supplied Hardware . . . . . . . . . . . . . . . . . . . . . . . . . 2
• INDOOR AIR QUALITY (CO
Mount Fan Coil Controller . . . . . . . . . . . . . . . . . . . . . . . . 2
• LOCATION
• MOUNTING
Connect the Power Transformer. . . . . . . . . . . . . . . . . . 4
Install Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
INSTALLATION
INSTALLATION
Connect the Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Connect Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Connect the CCN Communication Bus . . . . . . . . . . 26
START-UP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Perform System Check-Out . . . . . . . . . . . . . . . . . . . . . 27
Initial Operation and Test. . . . . . . . . . . . . . . . . . . . . . . . 27
CONFIGURATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27-44
Points Display Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Alarm Service Configuration Table . . . . . . . . . . . . . . 30
Controller Identification Screen . . . . . . . . . . . . . . . . . 31
Holiday Configuration Screen . . . . . . . . . . . . . . . . . . . 31
Occupancy Configuration Screen . . . . . . . . . . . . . . . 31
Runtime Configuration Screen . . . . . . . . . . . . . . . . . . 32
Set Point Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Service Configuration Selection. . . . . . . . . . . . . . . . . 34
Fan Coil Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Occupancy Maintenance Table . . . . . . . . . . . . . . . . . . 39
Fan Coil Maintenance Table . . . . . . . . . . . . . . . . . . . . . 40
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
PC 111
Book 1
4
Tab
11a 13a
Installation, Start-Up and
Part Number 33ZCFANCOL
Page
) SENSOR
2
Catalog No. 533-356
Printed in U.S.A.
Fan Coil Controller

SAFETY CONSIDERATIONS

SAFETY NOTE
Air-handling equipment will provide safe and reliable
service when operated within design specifications. The
equipment should be operated and serviced only by
authorized personnel who have a thorough knowledge
of system operation, safety devices and emergency
procedures.
Good judgement should be used in applying any manu-
facturer's instructions to avoid injury to personnel or dam-
age to equipment and property.
Disconnect all power to the unit before performing mainte-
nance or service. Unit may automatically start if power is
not disconnected. Electrical shock and personal injury
could result.
If it is necessary to remove and dispose of mercury contac-
tors in electric heat section, follow all local, state, and fed-
eral laws regarding disposal of equipment containing
hazardous materials.
Damage to equipment may result. An individual field-
supplied 24-VAC power transformer is required for each
fan coil controller. The transformer must be less than
100 VA to meet UL Class 2.

GENERAL

The Fan Coil Controller is a field retrofit, low cost, CCN
(Carrier Comfort Network) control for fan coil units. The fan
coil controller is a microprocessor-based direct digital control
(DDC) controller for fan coil units. It can be retrofitted on
direct drive fan units manufactured by Carrier or other manu-
facturers to provide precise temperature control for applica-
tions of 2,000 cfm or less.
The fan coil controller can function as either a stand-alone
control or as part of the CCN. User interfaces include the CCN
Service Tool, ComfortVIEW™, and ComfortWORKS
ware. When used as part of the CCN, other devices such as the
CCN Data Transfer, Linkage Thermostat, or Comfort Control-
ler can read data from or write data to the fan coil controller.
Form 33ZC-2SI
Pg 1
soft-
®
506
3-00
Replaces: New
