1600 psi electric pressure washer
Hide thumbs
Table of Contents

Advertisement

Quick Links

STANLEY® and the STANLEY® logo are trademarks of Stanley Black & Decker, Inc.
93902-KP
93902_16ARN027_1600_ENG-FR-SP.indd 1
1600 PSI
ELECTRIC PRESSURE
WASHER
ASSEMBLY, CARE AND
USE INSTRUCTIONS
Model SHP 1600
READ CAREFULLY
IMPORTANT:
RETAIN THESE INSTRUCTIONS AND ATTACH RE-
CEIPT TO MANUAL FOR FUTURE REFERENCE.
ALWAYS WEAR EYE PROTECTION TO PREVENT
INJURY TO EYES WHEN OPERATING THE POWER
WASHER.
Questions, problems, missing parts?
Before returning to your retailer, call our
customer service department at 1-866-508-1330,
8 a.m. - 5:00 p.m., CST, Monday - Friday.
www.stanleypressurewashers.com
© 2016 Stanley Black & Decker, Inc.
or an affiliate thereof and are used under license.
16/12/14 下午5:46

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SHP 1600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stanley SHP 1600

Summary of Contents for Stanley SHP 1600

  • Page 1 8 a.m. - 5:00 p.m., CST, Monday - Friday. www.stanleypressurewashers.com © 2016 Stanley Black & Decker, Inc. STANLEY® and the STANLEY® logo are trademarks of Stanley Black & Decker, Inc. 93902-KP or an affiliate thereof and are used under license.

  • Page 2: Table Of Contents

    Care and Maintenance ..................12 Troubleshooting ....................14 Limited Warranty ....................15 Replacement Parts List ..................16 PRODUCT SPECIFICATIONS SPECIFICATIONS Max PSI Max GPM Weight (lbs.) Model (lbs/sq. in.) (Gal/per min) Cold Water Volts Amps SHP 1600 1600 ✔ 93902_16ARN027_1600_ENG-FR-SP.indd 2 16/12/14 下午5:46...

  • Page 3: Package Contents

    PACKAGE CONTENTS OFF/O ON/I PW909112S PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Spray Gun Holster Detergent Bottle Handle Variable Spray Nozzle Lance Power Washer Unit Extension Lance Cord Hook O-Ring Replacement Kit Soft PVC High Pressure Hose Nozzle Cleaning Wire Spray Gun Screws Spray Gun Lock/Unlock HARDWARE CONTENTS...

  • Page 4: Safety Information

    SAFETY INFORMATION SAFETY INFORMATION Please read and understand this entire manual before DO NOT use your power washer when you are attempting to assemble, operate, or install the product. under the influence of alcohol or drugs. Use this power tool carefully and only when you are alert. This manual contains information that relates to 10.
  • Page 5 NEVER use lances or other parts that are not use hot water with your power washer. It compatible for this specific Stanley unit. NEVER will overheat and damage the high pressure pump. NEVER use an extension power cord since it...

  • Page 6: Assembly Instructions

    PREPARATION PREPARATION Before beginning assembly of product, make sure all Tools Required for Assembly (not included): Phillips parts are present. Compare parts with package contents screwdriver list and hardware contents list. If any part is missing or damaged, attempt to assemble the product. DO NOT Estimated Assembly Time: 5 minutes ASSEMBLY INSTRUCTIONS...
  • Page 7 ASSEMBLY INSTRUCTIONS OFF/O ON/I Slide cord hook holster (D) onto right side, when fac- Soft PVC High Pressure Hose Assembly ing unit, of power washer unit (C) as shown. Screw Soft PVC high pressure hose (E) clockwise onto bottom front of power washer unit (C). Pull back collar This step does not require any screws.
  • Page 8 ASSEMBLY INSTRUCTIONS Unlock Lock Extension Lance installation With spray gun (F) in locked position, attach extension lance (J) directly to spray gun. Insert lance extension into gun, pushing together and turning clockwise simultaneously. Turn the extension collar clockwise Locking Spray Gun (before Lance installation) To lock trigger of spray gun (F), point gun away from to lock into place.
  • Page 9 ASSEMBLY INSTRUCTIONS Variable Spray Nozzle Lance installation Detergent Bottle Installation Insert variable spray nozzle lance (I) or detergent bottle The detergent bottle comes with a straw which is (H) into the end of the extension lance by inserting and fitted into screw-on top. If you do not see the straw, pushing together turning clockwise simultaneously.

  • Page 10: Operating Instructions

    OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS Unlock • Turn the power switch to the “ON” (|) position. The unit will turn on for 1 - 2 seconds and shut off. This is a normal function of the auto start feature. Squeeze the spray gun trigger to begin pressure washing.
  • Page 11 OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS • Begin power washing by squeezing the trigger on the Operation Tips spray gun all the way into the handle. • If you hear the motor run intermittently when the • Release the spray gun trigger to stop the power washer trigger is not being squeezed, that is normal.

  • Page 12: Care And Maintenance

    CARE AND MAINTENANCE Detergents Cleaning Nozzles • Use detergents designed for power washers. These • A clogged or partially clogged nozzle can cause can be purchased online at our website www. significant reduction of water pressure coming out stanleypressurewashers.com. Hardware stores or of the nozzle and/or cause the unit to pulsate while home centers also have power washer detergents spraying.
  • Page 13 CARE AND MAINTENANCE Storage • When your pressure washing session has been • Remove high pressure hose from spray gun. completed, turn off the power switch located on • Remove lance from the gun. Place the gun in the the front of the power washer. Unplug the power holder on the side.

  • Page 14: Troubleshooting

    TROUBLESHOOTING If you have any questions regarding the product, please call customer service at 1-866-508-1330. PROBLEM CORRECTIVE ACTION Unit will not turn on. 1. The GFCI module on the end of the power cord must be plugged directly into an outlet.

  • Page 15: Limited Warranty

    LIMITED WARRANTY The Warranty of this product is coverd by A.R.North America. This product has a 2 (two) year warranty. Please read the following carefully to understand what each warranty entails: This product is under warranty to the original retail consumer against defects in material and workmanship for a period 1(one) year and is a complete “bumper to bumper”...

  • Page 16: Replacement Parts List

    © 2016 Stanley Black & Decker, Inc. Manufactured by: STANLEY® and the STANLEY® logo are trademarks of A.R. North America, Inc. Stanley Black & Decker, Inc. or an affiliate thereof 140 81 Avenue North East Fridley, MN 55432 and are used under license.
