How to Use

Indicator Lights and Buttons Description

❶
Indicator Lights
• In the working state, single white indicator
light stays on to indicate the current mode
of the stabilizer; The indicator for POV
mode blinks when the stabilizer is in Vortex
(V) mode.
• In the standby state, the four white indicator
lights blink slowly.
• In low power state, the red PF light blinks
slowly and the stabilizer automatically turns
off one minute later.
• When charging the stabilizer in power-off
state, the four white indicator lights will blink
one by one to indicate the current battery
level.
• The red PF indicator light will blink quickly
when charging the stabilizer without any
batteries.
• Single click the power button to check the
battery level.
One blinking indicator light: 0-25% battery
level.
Two blinking indicator lights: 25%-50%
battery.
Three blinking indicator lights: 50%-75%
battery level.
Four blinking indicator lights: 75%-100%
battery level.
❷
Joystick
• Four-way direction control of the camera/
lens on the stabilizer.
After Bluetooth connected, the SMOOTH-Q2 will be able to control the native cameras of some
mobile phones without ZY Play (applicable only to mobile phones that can use the volume button
as a shutter button; no password needed when connecting the mobile phone to the stabilizer via
Bluetooth).
❸
❹
• Single press to change stabilizer mode.
• Double press to return to the previous
mode.
• Long press for 2 seconds to enter or exit
standby mode
❸
Photo/Video Button
• Single click to take a photo in photo mode
in ZY Play App.
• Single click to start/stop recording video in
video mode in ZY Play App.
• Double click to switch between front
camera and rear camera in ZY Play App.
• Triple click to lift the tilt axis to avoid the
stabilizer arm appearing in the screen when
using ultra-wide phone cameras (Invalid in
Pan Following and Locking mode).
• After Bluetooth connected, the stabilizer
will be able to control the native cameras of
compatible mobile phones to take photos
or record videos.
❹
Power Button
• Long press the stabilizer to turn on/off the
stabilizer (release the button when the PF
indicator light blinks).
• Single click to check the battery level.
• Double click to reset the motors (invalid in
POV mode and Vortex mode).
• Triple click to enter Selfie mode (invalid in
Locking mode and Vortex mode)
❶
❷
