Mounting and Balancing Mobile Phone

Take out the phone holder from the packing box and mount it on the stabilizer according
to the following steps:
Loosen the latch;
❶
1
Extend the phone holder and put the phone into the phone holder
Do not turn on the stabilizer before the mobile phone is mounted.
Put the phone lens face up, then move the phone left or right until the phone is steady
and is almost level with the ground.

Mounting Phone Holder

Put the phoneholder
❷
close to the base plate;
2

Mounting Mobile Phone

1

Balancing Mobile Phone

Insert the phone holder
❸
into the slot and adjust it
to the middle part;
3
① After the balancing, if need to take out
the phone for other use, please take out
it along with the phone holder and insert
the phone holder into the slot to resume
use.
② Press down the horizontal arm to fold
up the stabilizer for storage after power-
off.
The balancing state of the mobile phone
has a great impact on stabilizer runtime.
The stabilizer can work even in the
unbalanced state but it will consume
more energy of the battery and reduce
stabilizer torque.
Tighten the
❹
latch.
4
