Installation

Installation of the exhaust pipe

The unit is a portable air conditioner that may be moved from room to room.
1. Using the extendable slide
Offer window spacer to the window gap and adjust the length as you need.
Feed exhaust hose through the window spacer and slide window across so
that spacer is held securely. This technique may also be used for sash windows.
Note: Take care to maintain protection against intruders.
2. Using the adaptor
Cut a 152mm diameter hole in the wall or window.
Feed exhaust hose through the window or wall and attach the threaded
adaptor from the outside as shown.
When not in use, plug the hole with the cover provided.
Extendable slide
FIG. 4
FIG. 5
FIG. 6
5
Wall or Window
Outward Adapter
