Components
1
3
1. Control panel
2. Carrying handle
3. Air outlet
4. Air filter
11. Exhaust hose
12. Adaptor - for insertion over hose and into window spacer
(or into hole in the wall/window).
13. Cover for adaptor
14. Drain tube for continuous drainage
15. Active carbon filter
16. Remote control
2
10
9
8
5. Exhaust air outlet
6. Air filter
7. Water stopper/
drainage point
11
4
7
8. Air inlet
9. Cord storage
10. Air inlet
12
13
4
5
6
14
15
