Draper Ultimate Access XL V Instructions Manual

Ultimate Access XL E & V
Electric Projection Screen
Overview - Components
"V " Fl ex ib le Vi ny l
Vi ew in g Su rf ac e

Section 1 - Removing Shipping Brackets

(Tab-Tensioned, "V" Surfaces only)
Caution: DO NOT remove shipping brackets until product has been mounted and connected to
power (see Section 4 in this
removing shipping brackets from screen case.
Section 2 - Hanging Screen
Please Note: When locating viewing surface and
checking clearance for screen operation, ensure that
surface is centered in the case.
1. Engage each case mounting bracket
with top of housing (Fig. 2) and tighten set screws.
2. Screen should be sufficiently supported to withstand
vibration.
Please Note: A hoisting bracket is included on each
end of the case to aid in overhead installation.
3. Ensure that fasteners are of adequate strength and
suitable for the mounting surface chosen. Supporting
hardware such as chains, cables, two
rods, etc., must be precisely vertical.
4. Entire bottom of case must be readily accessible after installation is complete.
5. Front, back and top of case must be straight—not forced to warp or bow.
Caution: Screen case and flange are not designed to serve as ceiling support.
6. Do not seal unit in ceiling until electrical connections have been made and screen
operates successfully.
Please Note: If case is painted on location, removal of roller/fabric assembly is
recommended prior to painting. If not removed, slot on bottom of case should be
shielded to protect viewing surface from paint splatters/overspray.
"E " Fr ee Ha ng in g
Vi ew in g Su rf ac e
document.). Also, DO NOT OPERATE SCREEN BEFORE
HOISTING HOISTING
BRACKET BRACKET
(attached to case)
TYPICAL TYPICAL
/ " (9.5 mm)
3
8
INSTALLATION INSTALLATION
INSTRUCTIONS
INSTALLATION & OPERATION
Please Note: Shipping brackets must remain in place
until product has been mounted and connected to
power (see Sections 1 and 4 in this
Also, DO NOT operate screen before removing
shipping brackets from screen case.
TOOLS REQUIRED
PENCIL POWER DRILL
1. Remove Fasteners
from Bracket Clamps
4. Retighten dowel
endcap screws.
Figure 2
Installation of Case
CASE CASE
MOUNTING MOUNTING
BRACKET BRACKET
7 / " 7 / "
8 8
ELECTRICAL ELECTRICAL
CUTOUT CUTOUT
ALTERNATE
INSTALLATION
Additional set of brackets required
but NOT included.
Read and understand all warnings (p. 2)
before beginning installation.
If you have any difficulties installing or servicing your
Ultimate Access XL Screen, call your dealer or Draper, Inc.
Draper, Inc. | 411 S. Pearl St. Spiceland, IN 47385
draperinc.com | 765.987.7999 | 800.238.7999
© 2019 All Rights Reserved
document.).
TAPE MEASURE HARDWARE LEVEL
(by others)
Figure 1
2. Run the screen
DOWN to expose
the Dowel Screws
3. Loosen screws
and remove the
shipping bracket.
HOISTING HOISTING
BRACKET BRACKET
CASE
MOUNTING
BRACKETS
ALTERNATE
INSTALLATION
Additional set of brackets required
but NOT included.
CAUTION
|
FORM: UltimateAccessXL_Inst19
CASE
MOUNTING
BRACKETS
