Trouble condition
• If the panel indicates a tamper condition for this device,
check that the cover is securely in place and that the
spring is on the tamper switch.
• If the panel indicates a low battery condition for this
device, replace the DTIM battery and conduct a phone
test.
• If the panel indicates a phone failure condition for this
device, make sure the phone line is connected.
Module supervisory
If the panel indicates a DTIM supervisory condition, use an RF
Sniffer (60-401) to verify that the DTIM transmits when the
cover is removed and replaced. If it does not transmit, check
the battery and replace it if necessary.
If the sniffer indicates that the DTIM is transmitting, it may be
out of panel receiving range. Use the sensor test to verify that
the DTIM is within panel range. If necessary, test the DTIM
from other locations until an acceptable location is found.

Specifications

Power source 3.6 V AA lithium battery
Wireless range 500 ft. (152 m) open-air (nominal)
Dimensions (W × H × 4.0 × 6.25 × 1.0 in. (10 × 16 × 2.5 cm)
D)
Compatible panels Allegro, Simon 3 version 4.1 and higher
Operating environment
Temperature 32 to 120°F (0 to 49°C)
Humidity 90% RH, noncondensing
Storage environment
Temperature -30 to 140°F (-34 to 60°C)

Certification and compliance

FCC Part 15 information to the user
Changes or modifications not expressly approved by UTC Fire
& Security can void the user's authority to operate the
equipment.
FCC Part 15 Class B
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC rules. These limits are designed to provide reasonable
protection against interference in a residential installation.
Dialog Telephone Interface Module Installation Sheet
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the affected equipment and the panel receiver to
separate outlets, on different branch circuits.
• Consult the dealer or an experienced radio/TV technician.
FCC part 15 ID No. B4Z-786A-DTIM
IC: 867A-DTIM
ACTA Part 68
This equipment complies with Part 68 of the FCC rules.
Located on this equipment is a label that contains, among
other information, the FCC registration number and the ringer
equivalence number (REN) for this equipment. If requested,
this information must be provided to the telephone company.
FCC Part 68 Registration No. B4Z-AL01B46059
The REN is used to determine the maximum number of
devices that may be connected to your telephone line.
Excessive RENs on a telephone line may result in devices not
ringing in response to an incoming call. In most areas, the sum
of all device RENs should not exceed five. To be certain of the
number of devices that may be connected to a line, as
determined by the total RENs, contact the local telephone
company. For products approved after July 23, 2001, the REN
for this product is part of the product identifier that has the
format US:AAAEQ##TXXXX. The digits represented by ## are
the REN without a decimal point (e.g., 03 is a REN of 0.3). For
earlier products, the REN is shown separately on the label.
A plug and jack used to connect this equipment to the
premises wiring and telephone network must comply with the
applicable FCC Part 68 rules and requirements as adopted by
ACTA. A compliant telephone cord and modular plug is
provided with this product. It is designed to be connected to a
compliant modular jack that is also compliant. See the
installation instructions for details.
Alarm dialing equipment must be able to seize the telephone
line and place a call in an emergency situation. It must be able
to do this even if other equipment (telephone, answering
system, computer modem, etc.) already has the telephone is
