User's Manual
Regulated DC Power Supply
PAT-T Series
8 kW type
PAT20-400T
PAT30-266T
PAT40-200T
PAT60-133T
PAT80-100T
PAT160-50T
PAT250-32T
PAT350-22.8T
PAT500-16T
PAT650-12.3T
PAT850-9.4T
PART NO. Z1-004-772, IB020522
Dec. 2010
Description
Installation and
Preparation
Connecting the Load
Basic Operation
External Control
Parallel/Series Operation
Remote Control
Maintenance
Specifications
General
1
2
3
4
5
6
7
8
Appx
